| Product properties | Product type: Device marking Marking Number of individual labels: 4 Number of individual labels per row: 1 Identification technology: UV LED technology |
| Mounting | Mounting type: screw, rivet |
| Material specifications | RoHS compliant: yes Color: red Material: PA Flammability rating according to UL 94: V2 Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)): 120°C Fire protection for rail vehicles (DIN EN 45545-2) R22: HL 1 - HL 2 Fire protection for rail vehicles (DIN EN 45545-2) R23: HL 1 - HL 2 Fire protection for rail vehicles (DIN EN 45545-2) R24: HL 1 - HL 2 Components: free from silicone and halogen |
| Environmental and real-life conditions | Test for substances that would hinder coating with paint or varnish Result: Test passed UV resistance Specification: ISO4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Wipe resistance of inscriptions Specification: DINEN61010-1 (VDE0411-1):2011-07 DINEN62208 (VDE0660-511):2012-06 (in parts) Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DIN50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINEN60068-2-11:2000-02 Result: Test passed Ambient conditions Ambient temperature (operation): -40°C ... 120°C Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/667274d3ff673148999b75e4433ed17b/-S204x204-FJPG Width: 60 mm Length: 15 mm Hole diameter: 3.20 mm |
| Standards and regulations | Wipe resistance: DINEN61010-1 (VDE0411-1) |
| ECLASS | ECLASS-11.0: 27281103 ECLASS-12.0: 27281103 ECLASS-13.0: 27281103 |
| ETIM | ETIM 9.0: EC001288 |
| UNSPSC | UNSPSC 21.0: 39131500 |
