Not available
| Notes | General: Can be labeled with CMS |
| Product properties | Product type: Terminal marking Pitch: 6.2 mm Type: Label Marking Number of individual labels: 120 Number of individual labels per row: 10 Number of marker strips: 12 Printing: without print Identification technology: manually |
| Dimensions | Width: 6.2 mm Height: 3.8 mm Pitch: 6.2 mm |
| Material specifications | Foil strength: 53 õm Adhesive strength: 20 õm Adhesive: Acrylic Color: white Material: Polyester Components: free from silicone and halogen |
| Environmental and real-life conditions | Test for substances that would hinder coating with paint or varnish Result: Test passed UV resistance Specification: ISOÃ4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Wipe resistance of inscriptions Specification: DINÃENÃ61010-1 (VDEÃ0411-1):2011-07 DINÃENÃ62208 (VDEÃ0660-511):2012-06 (in parts) Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DINÃ50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINÃENÃ60068-2-11:2000-02 Result: Test passed Ambient conditions Ambient temperature (operation): -40°C ... 150°C Ambient temperature (assembly): > 15°C Recommended storage conditions: 23°C / 50% relative humidity. Storage in the original packaging is recommended prior to processing. Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % Shelf life: 12Ãmonths |
| Standards and regulations | Wipe resistance: DINÃENÃ61010-1 (VDEÃ0411-1) |
| Mounting | Mounting type: adhesive |
