| Product properties | Product type: Labeled conductor marker Type: Card form Marking Number of individual labels: 32 Number of individual labels per row: 8 |
| Mounting | Mounting type: clip on |
| Material specifications | RoHS compliant: yes Color: white Material: PC Flammability rating according to UL 94: V0 Relative insulation material temperature index (Elec., UL 746 B): 130°C Fire protection for rail vehicles (DIN EN 45545-2) R22: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R23: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R24: HL 1 - HL 3 Components: free from silicone, halogen, and cadmium |
| Environmental and real-life conditions | Test for substances that would hinder coating with paint or varnish Result: Test passed UV resistance Specification: ISOÃ4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Ambient conditions Ambient temperature (operation): -40°C ... 120°C Recommended storage conditions: 23ðC/50Ã% relative humidity. Storage in a dry and dark place in the original packaging is recommended. Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % |
| Dimensions | Width: 4 mm Length: 12 mm External dimensions Outside diameter: 2 mm ... 2.9 mm |
| Standards and regulations | Wipe resistance: DINÃENÃ61010-1 (VDEÃ0411-1) |
