0832082 PHOENIX CONTACT - Technology Bsa

EMT (50/28X13)R RD - Insert label

Insert label, For marking Siemens ET 200S controllers, Roll, red, unlabeled, can be labeled with: THERMOMARKE.300 (D)/600 (D), THERMOMARK ROLL 2.0, THERMOMARK ROLL, THERMOMARK ROLL X1, THERMOMARK ROLLMASTER 300/600, THERMOMARK X1.2, mounting type: insert, lettering field size: 1x50mmx13mm, 1x28mmx13mm, Number of individual labels: 500

Product Code: 0832082

Partner cod.: 0832082

PHOENIX CONTACT

Product properties	Controller type: For marking Siemens ET 200S controllers Product type: Device marking Area of application: SIEMENS: ET 200S controller Marking Number of individual labels: 500 Number of individual labels per row: 2 Identification technology: Thermal transfer for rolls
Mounting	Mounting type: insert
Material specifications	Color: red Material: Polyester Components: free from silicone and halogen
Environmental and real-life conditions	Test for substances that would hinder coating with paint or varnish Result: Test passed Scratch test for the determining scratch resistance Specification: DINÃENÃISOÃ1518-1:2019-10 (following) Requirements: Ã¢Ã¢°¥Ã5ÃN Result: Test passed Tesafilm test Specification: DINÃENÃISOÃ2409:2013 (following) Result: Test passed UV resistance Specification: ISOÃ4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Temperature resistance Specification: ANSI/ULÃ969-2018:03 (following) Test duration: 240 h Rating 150Ã°C (180Ã°C): Test passed Salt spray test Specification: DINÃENÃ60068-2-11:2000-02 Result: Test passed Test duration: 96 h Ambient conditions Ambient temperature (operation): -40°C ... 120°C Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % Shelf life: 2Ãyears
Dimensions	Width: 77.5 mm Length: 12.8 mm
Standards and regulations	Wipe resistance: DINÃENÃ61010-1 (VDEÃ0411-1)
