Product properties | Product type: Data cable preassembled Sensor type: Ethernet Number of positions: 12 No. of conductors: 12 |
Electrical properties | Attenuation: typ. 0.35 dB Transmission medium: Multi-mode fiberglass |
Mechanical properties | Tensile strength short-term/long-term: 500 N / 200 N |
Material specifications | Ferrule material: Zirconia ceramics Outer sheath, material: LSFH |
Connector | Connection 1 Material: Stainless steel Degree of protection: IP68 (IEC 60529) Number of positions: 12 Locking type: Screw locking mechanism Connection 2 Handle color: beige Material: Plastic Number of positions: 12 Degree of protection: IP20 (IEC 60529) Locking type: Push Pull |
Cable/line | Cable length: 0.6 m Cable weight: 8.30 kg/km Cable type: Multimode fiberglass Fan out Cable abbreviation: 12-.../(ZN)H-...30 External cable diameter: 7 mm Outer sheath, material: LSFH External sheath, color: orange Wire diameter incl. insulation: 250 µm Tensile strength short-term/long-term: 500 N / 200 N Lateral pressure short term: 500.00 N/cm Lateral pressure, long-term: 100.00 N/cm Halogen-free: complying with IEC 60754-1/2 FO cable Number of fibers: 12 Fiber: 62.5/125µm OM1 Fiber type: Multimode fiberglass 62.5/125µm Transmission medium: Multi-mode fiberglass |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 70°C Ambient temperature (storage/transport): -20°C ... 70°C Ambient temperature (assembly): -10°C ... 50°C |
ECLASS | ECLASS-11.0: 27061803 ECLASS-13.0: 27061803 ECLASS-12.0: 27061803 |
ETIM | ETIM 9.0: EC000034 |
UNSPSC | UNSPSC 21.0: 26121600 |
