Notes | General: NOTE: Observe the permissible bending radii when laying conductors, since the degree of protection may be put in jeopardy if the bending forces are too high. Alleviate mechanical loads upstream of the connector, e.g.by using cable ties. |
Mounting | Assembly instructions: Contacts can be clipped in place and unclipped without tools The pin assignment can be rotated in a 30° pitch to the cable outlet Connection method: Crimp connection |
Product properties | Product type: Circular connector (cable-side) Sensor type: Universal Number of positions: 5 No. of cable outlets: 1 Shielded: yes Coding: A Cable outlet: angled Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/eec7af1ddc73d74bbc73b363b191b97f/-S204x204-FJPG Wrench size, union nut: 15 mm Wrench size, counter nut: 14 mm External dimensions Outside diameter: 4.5 mm ... 7.5 mm Housing Diameter housing: 22 mm |
Material specifications | Flammability rating according to UL 94: V0 Seal material: NBR Material of grip body: Zinc die-cast, nickel-plated Contact carrier material: PA 6.6 Material for screw connection: Zinc die-cast, nickel-plated Standards/regulations: PA 6.6: Fire protection in rail vehicles - requirement sets R22, R23, R24, and R26 acc. to DINEN45545-2 (Risk level HL1 - HL3) |
Connection data | Conductor connection Connection method: Crimp connection Connection cross section: 0.14 mm² ... 1 mm² (flexible) Connection cross section AWG: 26 ... 18 (flexible) Stripping length of the individual wire: 4 mm +0,5mm Tightening torque: 1.5 Nm (Screw plug insert with sleeve housing as far it will go) 4 Nm (Pressure nut with coupling sleeve) |
Electrical properties | Rated surge voltage: 1.5 kV Insulation resistance: ⥠100 Mé Nominal voltage UN: 60 VDC 48 VAC Nominal current IN: 4 A |
Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠100 |
Connector | Connection 1 Head design: Socket Head cable outlet: angled Head thread type: M12 Head locking type: Push-Pull Coding: A |
Cable/line | Signal type/category: Universal Stripping length of the individual wire: 4 mm +0,5mm |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 Ambient temperature (operation): -40°C ... 85°C (Plug / socket) |
Standards and regulations | Testing Standards/regulations: PA 6.6: Fire protection in rail vehicles - requirement sets R22, R23, R24, and R26 acc. to DINEN45545-2 (Risk level HL1 - HL3) Standard designation: M12 connector Shock, vibration Standards/specifications: IEC 61076-2-101 EN50155:2001 Note: In line with |
