A-INSP-M16-68N-P-LG - Screw plug

Screw plug, material for screw connection: PA, connecting thread: M16 x 1.5, color: lightgrey RAL7035, with O-ring

Product Code: 1045818

Partner cod.: 1045818

PHOENIX CONTACT

Tecnichal data

Download

Tecnichal data

Product properties	Product type: Plug for cable screw gland Manufacturer: WISKA Manufacturer Designation: EVSG-ORDÃ16
Connection data	Tightening torque: 1 Nm
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/e1eab553b5b8b149a3bc40fe79a2466f/-S204x204-FJPG Height: 9 mm Length: 9 mm Length of the connecting thread: 6 mm Thread type connection side: M16 x 1.5 Thread pitch: 1.5 mm
Material specifications	Seal material O-ring: EPDM Material for screw connection: PA
Environmental and real-life conditions	Ambient conditions Degree of protection: IP68 IP66 Ambient temperature (operation): -40°C ... 100°C

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Technical_drawing_06400.pdf
