Product properties | Type: Header perpendicular to the PCB Product type: PCB headers Product family: MSTBO 2,5/..-G1L THR Au Number of positions: 3 Pitch: 5 mm Pin layout: Linear pinning Solder pins per potential: 1 |
Electrical properties | Degree of pollution: 3 Contact resistance: 1.61 mé |
Mounting | Mounting type: THR soldering Pin layout: Linear pinning Connection method: THR solder connection |
Material specifications | Material data - housing Color (Housing): black (9005) |
Dimensions | Pitch: 5 mm Width [w]: 14.95 mm Height [h]: 16.5 mm Length [l]: 15.35 mm Solder pin length [P]: 2.5 mm Pin dimensions: 1 x 1 mm PCB design Hole diameter: 1.5 mm |
Mechanical tests | Visual inspection Specification: IEC 60512-1-1:2002-02 Result: Test passed Dimension check Specification: IEC 60512-1-2:2002-02 Result: Test passed Resistance of inscriptions Specification: IEC 60068-2-70:1995-12 Result: Test passed Polarization and coding Specification: IEC 60512-13-5:2006-02 Result: Test passed Contact holder in insert Specification: IEC 60512-15-1:2008-05 Contact holder in insert Requirements >20 N: Test passed Insertion and withdrawal forces Result: Test passed No. of cycles: 25 Insertion strength per pos. approx.: 7 N Withdraw strength per pos. approx.: 6 N |
Electrical tests | Thermal test | Test group C Specification: IEC 60512-5-1:2002-02 Tested number of positions: 4 Insulation resistance Specification: IEC 60512-3-1:2002-02 Insulation resistance, neighboring positions: 1012é |
Environmental and real-life conditions | Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 500 - 10 Hz Sweep speed: 1octave/min 5g (60.1Hz...150Hz) Amplitude: 0.35mm (10Hz...60.1Hz) Test duration per axis: 2 h Durability test Specification: IEC 60512-9-1:2010-03 Impulse withstand voltage at sea level: 4.8 kV Contact resistance R1: 1.61 mé Contact resistance R2: 1.62 mé Insertion/withdrawal cycles: 25 Insulation resistance, neighboring positions: >1012é Climatic test Specification: ISO6988:1985-02 Corrosive stress: KFW 0.2 S/1 cycle Thermal stress: 100°C/168h Power-frequency withstand voltage: 2.25 kV Ambient conditions Ambient temperature (operation): -40°C ... 105°C (dependent on the derating curve) Ambient temperature (storage/transport): -40°C ... 55°C Relative humidity (storage/transport): 30 % ... 70 % Ambient temperature (assembly): -5°C ... 100°C |
Packaging specifications | Type of packaging: 44 mm wide tape [W] tape width: 44 mm Outer packaging type: Transparent-Bag |
ECLASS | ECLASS-11.0: 27460201 ECLASS-12.0: 27460201 ECLASS-13.0: 27460201 |
ETIM | ETIM 9.0: EC002637 |
UNSPSC | UNSPSC 21.0: 39121400 |
