Not available
| Product properties | Product type: Reducing adapter Seal present: yes |
| Dimensions | Dimensional drawing: https://caas.production.phoenixcontact.coremedia.cloud/caas/v1/stable/media/22638/full/b250?format=jpg Width: 26.50 mm Length: 12 mm Length of the connecting thread: 6.5 mm Hexagon angular dimension: 26.5 mm Thread type connection side: M20 x 1.5 Thread pitch: 1.5 mm |
| Material specifications | Material: Polyamide fiberglass reinforced Flammability rating according to UL 94: HB Seal material: NBR |
| Cable/line | Halogen-free: no |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 (Depends on the screw connection used) Ambient temperature (operation): -30°C ... 100°C |
| Mounting | Assembly instructions: With corresponding screw connection: IP65 |
| ECLASS | ECLASS-11.0: 27144492 ECLASS-12.0: 27144492 ECLASS-13.0: 27140806 |
| ETIM | ETIM 9.0: EC000938 |
| UNSPSC | UNSPSC 21.0: 31261500 |
