1096323 PHOENIX CONTACT - Technology Bsa

EMLP (60X15)R RD - Label

Label, Roll, red, unlabeled, can be labeled with: THERMOMARKE.300 (D)/600 (D), THERMOMARK ROLL 2.0, THERMOMARK ROLL, THERMOMARK ROLL X1, THERMOMARK ROLLMASTER 300/600, THERMOMARK X1.2, mounting type: adhesive, lettering field size: 60x15mm, Number of individual labels: 500

Product Code: 1096323

Partner cod.: 1096323

PHOENIX CONTACT

Product properties	Product type: Device marking Marking Number of individual labels: 500 Number of individual labels per row: 1 Identification technology: Thermal transfer for rolls
Mounting	Mounting type: adhesive
Material specifications	RoHS compliant: yes Foil strength: 50 µm Adhesive strength: 20 µm Adhesive: Acrylic Color: red Material: Polyester Components: Silicone-free
Environmental and real-life conditions	Test for substances that would hinder coating with paint or varnish Result: Test passed Scratch test for the determining scratch resistance Specification: DINENISO1518-1:2019-10 (following) Requirements: Ã¢¥5N Result: Test passed Tesafilm test Specification: DINENISO2409:2013 (following) Result: Test passed UV resistance Specification: ISO4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Temperature resistance Specification: ANSI/UL969-2018:03 (following) Test duration: 240 h Rating 125°C (150°C): Test passed Wipe resistance of inscriptions Specification: DINEN60068-2-11:2000-02 DINEN62208 (VDE0660-511):2012-06 (in parts) ISO175:2010 (following) Test duration: 168 h IRM 901: Test passed IRM 902: Test passed Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DIN50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINEN60068-2-11:2000-02 Result: Test passed Test duration: 96 h Ambient conditions Ambient temperature (operation): -40°C ... 120°C Ambient temperature (assembly): > 18°C Recommended storage conditions: 23°C/50% relative humidity. Storage in a dry and dark place in the original packaging is recommended. Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % Shelf life: 12months
Dimensions	Width: 60 mm Length: 15 mm
Standards and regulations	Wipe resistance: DINEN61010-1 (VDE0411-1)
