| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/7f63a78101df0a4bb82c262df3d9b2e0/-S204x204-FJPG Width: 60 mm Height: 226 mm Depth: 46 mm |
| Notes | General: Support by phone or on-site (fee is charged) |
| Material specifications | Housing material: Zinc die-cast |
| Mounting | Mounting type: Wall mounting |
| Interfaces | Ethernet Connection method: M12 connectors, D-coded Note on the connection method: Auto negotiation and autocrossing Transmission speed: 10/100 Mbps Transmission physics: Copper Transmission length: 100 m (per segment) Signal LEDs: Data receive, link status No. of channels: 8 (M12 ports) |
| Product properties | Type: Stand-Alone Product type: Switch Product family: Managed Switch 2000 MTTF: 461.15 Years (SN29500 standard, temperature25°C, operating cycle21%) 149.69 Years (SN29500 standard, temperature40°C, operating cycle34.25%) 19.78 Years (SN29500 standard, temperature70°C, operating cycle100%) Special properties: Extended temperature range Signal delay: ⥠6.5 µs (Store and Forward mode, 10/100 Mbps, depending on the frame size) Insulation characteristics Protection class: III (VDE0106) Switch functions Diagnostic functions: RMON History LLDP (Link Layer Discovery Protocol) SNMP-Traps N:1-Portmirroring ACD (Address Conflict Detection) SysLog CRC-Surveillance Basic functions: Store-and-forward switch, complies with IEEE802.3 PROFINET conformance class: Conformance-Class B PROFINET device function: PROFINET device Fast Startup Filter functions: Quality of Service (8 priority classes) Class of Service DiffServ/DSCP Port-Priorisierung VLAN (up to 32 VLANs) IGMP Snooping/Querier (v1/v2) Auto-Query-Port Extended Multicast Filtering IP parameterization: DHCP-Client DHCP Option 82 (Relay Agent) DHCP server (pool-based, port-based) BootP DCP (Discovery and Configuration Protocol) MAC address table: 8k Management: Web-based management (HTTP/HTTPS) Role-based user management (LDAP, RADIUS) SNMPv1/v2/v3 Command Line Interface (Telnet, SSH) Redundancy: MRP (Media Redundancy Protocol) RSTP (Rapid Spanning Tree Protocol) FRD (Fast Ring Detection) Large Tree Support LACP (Link Aggregation Control Protocol) PROFINET S2 system redundancy Status and diagnostic indicators: LEDs: US1, US2 (power supply), Fail, 2 LEDs per Ethernet port (Link/Activity and Speed) Additional functions: Transmission of MMSandGOOSE (IEC 61850-8-1) Transmission of Modbus/TCP Time synchronization: SNTP (Simple Network Time Protocol) Security functions Port security: MAC-based, RADIUS (IEEE 802.1X), MAC Authentication Bypass Basic functions: Store-and-forward switch, complies with IEEE802.3 |
| Electrical properties | Local diagnostics: US1/2 Supply voltage US1, US2 Green LED FAIL Div. LED red LINK Link status Green LED Maximum power dissipation for nominal condition: 4.68 W (US = min, Tamb = max) Test section: for one minute 500 VDC Transmission medium: Copper Supply Supply voltage (DC): 24 VDC (redundant) Supply voltage range: 9 VDC ... 57 VDC Residual ripple: 3.6 VPP (within the permitted voltage range) Max. current consumption: 0.52 A (US = min, Tamb = max) Typical current consumption: 180 mA (at US = 24VDC and 25°C ambient temperature) Current consumption: 180 mA |
| Connection data | Connection method: M12 connector (A-coded) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP66 IP67 Ambient temperature (operation): -40°C ... 70°C Ambient temperature (storage/transport): -40°C ... 85°C Permissible humidity (operation): 5 % ... 95 % Permissible humidity (storage/transport): 5 % ... 95 % Shock (operation): 30g (EN60068-2-27) Vibration (operation): in acc. with IEC 60068-2-6: 5g, 150 Hz Air pressure (operation): 79 kPa ... 108 kPa up to 2000m above mean sea level (Without derating) Air pressure (storage/transport): 79 kPa ... 108 kPa up to 2000m above mean sea level (Without derating) |
| Standards and regulations | Free from substances that could impair the application of coating: Yes |
| EMC data | Conformance with EMC directives: EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion A EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A EN 61000-6-2 EN 61000-4-5 (surge) Criterion B EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A EN 61000-6-3 (conducted emissions) ClassB EN 61000-6-3 (conducted emissions) ClassB Noise immunity: EN 61000-6-2 Electromagnetic compatibility: Conformance with EMC Directive 2014/30/EU Noise emission: EN 61000-6-3 |
| System properties | Functionality Basic functions: Store-and-forward switch, complies with IEEE802.3 |
| Signaling | Status display: LEDs: US1, US2 (power supply), Fail, 2 LEDs per Ethernet port (Link/Activity and Speed) |
| ECLASS | ECLASS-11.0: 19170401 ECLASS-12.0: 19170401 ECLASS-13.0: 19170401 |
| ETIM | ETIM 9.0: EC000734 |
| UNSPSC | UNSPSC 21.0: 43222600 |
