PHOENIX CONTACT 1141312

Not available

EG 22,5-A/PC KMGY - Upper part of housing

Component housing, Cover, for two-sided connection, width: 22.5 mm, height: 75 mm, color: light grey (7035)

Product Code: 1141312

Partner cod.: 1141312

PHOENIX CONTACT

Tecnichal data

Technical Specs

Download

Tecnichal data

Product properties	Product type: Upper housing part Product family: EG Number of positions: 8 Type: Cover, for two-sided connection Housing type: Component housing Ventilation openings present: no Housing series: EG
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/fdd7f57abcbd3549ae1e3573c4fc7dee/-S204x204-FJPG Width: 22.5 mm Height: 75 mm PCB design PCB thickness: 1.4 mm ... 1.8 mm
Material specifications	Color: light grey (7035) Flammability rating according to UL 94: V0 Surface characteristics: untreated Housing material: Polycarbonate
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 100°C
PCB data	Thickness of the PCB: 1.4 mm ... 1.8 mm
Mounting	Mounting type: Snap in Mounting position: Vertical (horizontal DIN rail)

Technical Specs

ECLASS	ECLASS-11.0: 27182702 ECLASS-13.0: 27190603
ETIM	ETIM 9.0: EC001031
UNSPSC	UNSPSC 21.0: 31261500

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Material_description_00001.pdf
