1155594 PHOENIX CONTACT - Technology Bsa

ES-BPC-C 50-70 OG - Connector

Connector, Range of articles: BPC, color: orange, number of positions: 1, min. conductor cross section: 50 mm², max. conductor cross section: 70 mm², rated voltage: 1500, rated current: 250 A, Connection method: Crimp, Contact connection type: Socket, min. cable diameter: 11.3 mm, max. cable diameter: 17 mm

Product Code: 1155594

Partner cod.: 1155594

PHOENIX CONTACT

Notes	Safety note Safety note: Ã¢¢ WARNING: Commission properly functioning products only. The products must be regularly inspected for damage. Decommission defective products immediately. Replace damaged products. Repairs are not possible. Ã¢¢ WARNING: Only electrically qualified personnel may install and operate the product. They must observe the following safety notes. The qualified personnel must be familiar with the basics of electrical engineering. They must be able to recognize and prevent danger. The relevant symbol on the packaging indicates that only personnel familiar with electrical engineering are allowed to install and operate the product. WARNING: The connectors may not be plugged in or disconnected under load. Ignoring the warning or improper use may damage persons and/or property. Ã¢¢ The products are suitable for applications in plant, controller, and electrical device engineering. Ã¢¢ Assembled products may not be manipulated or improperly opened. Ã¢¢ Only use mating connectors that are specified in the technical data of the standards listed (e.g. the ones listed in the product accessories online at phoenixcontact.com/products). Ã¢¢ When using the product in direct connection with third-party manufacturers, the user is responsible. Ã¢¢ For operating voltages > 50V AC, conductive connector housings must be grounded Ã¢¢ Ensure that the protective or functional ground has been properly connected. Ã¢¢ Observe the corresponding technical data. You will find information: o On the product o On the packing label o In the supplied documentation o Online at phoenixcontact.com/products under the product Ã¢¢ The installation notes/Design In documents online on the download page at phoenixcontact.com/products must be observed for this product. Ã¢¢ Use a protective cap to protect connectors that are not in use. The suitable accessories are available online in the accessory section of the product at phoenixcontact.com/products Ã¢¢ The connector warms up in normal operation. Depending on the ambient conditions, the surface of the connector can continue to warm up. In this case, the user is responsible for posting warnings (e.g. DIN EN ISO 13732-1:2008-12). Ã¢¢ Operate the connector only when it is fully plugged in and interlocked. Ã¢¢ Ensure that when laying the cable, the tensile load on the connectors does not exceed the upper limit specified in the standards. Ã¢¢ Observe the minimum bending radius of the cable. Lay the cable without twisting it.
Product properties	Product type: Connectors for energy storage Product family: BPC Number of positions: 1 Insulation characteristics Degree of pollution: 2
Electrical properties	Rated voltage (III/2): 1500 VDC Nominal voltage ATD: 1500 (III/2) Rated current: 250 A (with 70mm² conductor cross-section, in accordance with IEC 61984) 200 A (with 50mm² conductor cross-section, in accordance with IEC 61984) 250 A (with AWG 2/0, in accordance with UL4128) Contact resistance: Ã¢¤ 0.5 mÃ© Insulation resistance: 1000 MÃ© Nominal voltage U_N: 1500 V
Material specifications	Color: orange Material: Polyamide Copper Silicon Flammability rating according to UL 94: V0 Seal material: Silicon Insulating material: PA Contact material: Cu/Cu alloy
Cable/line	External cable diameter: 11.3 mm ... 17 mm Single wire, cross section: 50 mm² 70 mm² Stripping length of the individual wire: 20 mm ±1mm
Mechanical properties	Mechanical data Insertion/withdrawal cycles: 100 Insertion force: Ã¢¤ 75 N Withdrawal force: Ã¢¥ 10 N
Environmental and real-life conditions	Ambient conditions Degree of protection (when plugged in): IP65 (Mating socket) Degree of protection (not plugged in): IP20 Degree of protection: IP65 Ambient temperature (operation): -40°C ... 80°C Ambient temperature (storage/transport): -40°C ... 80°C Altitude: 4000 m
Standards and regulations	Standards/specifications: IEC 61984:2008 EN61984:2008 UL4128 PPP51090A
Mounting	Assembly instructions: We recommend using the crimping dies and other crimping devices of Jiangsu Bozhiwang Automation Equipment Co., Ltd. for cable crimp connections; address: No. 39 Kun Lun Road, Xin Bei District, Changzhou, Jiangsu Province, China, email: flacz2020@163.com, die model: BZW-6F Connection method: Crimp
