| Product properties | Product type: Component housing lower part Product family: UM-BASIC 122 Type: Basic profile Housing type: Press-drawn section housings Housing series: UM |
| Dimensions | Depth: 19.8 mm Length: 183.8 mm Internal dimensions Profile width (internal): 122 mm PCB design PCB thickness: 1.4 mm ... 1.8 mm |
| Material specifications | Color: light grey Flammability rating according to UL 94: V0 Housing material: PVC |
| Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -15°C ... 50°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 50°C Ambient temperature (assembly): -5°C ... 50°C Relative humidity (storage/transport): 95 % |
| PCB data | Thickness of the PCB: 1.4 mm ... 1.8 mm |
| Mounting | Mounting type: Latching with side elements, latching with foot element Mounting position: parallel to the DIN rail |
