| Product properties | Product type: Conductor marking Type: Label Marking Number of individual labels: 2250 Number of individual labels per row: 1 Identification technology: Thermal transfer for rolls |
| Dimensions | Width: 50.8 mm Length: 70 mm |
| Material specifications | RoHS compliant: yes Adhesive: Acrylic Color: white Material: PVC Components: Silicone-free |
| Cable/line | External cable diameter: 16.2 mm 8.1 mm ... 16.2 mm |
| Environmental and real-life conditions | Scratch test for the determining scratch resistance Specification: DINENISO1518-1:2019-10 (following) Requirements: â¥5N Result: Test passed Tesafilm test Specification: DINENISO2409:2013 (following) Result: Test passed UV resistance Specification: ISO4892-2:2013-03 (following) IEC 60068-2-2:2007-07 Result: Test passed Test duration: 96 h Duration: 96h Temperature for testing: 100°C Temperature resistance Specification: ANSI/UL969-2018:03 (following) ISO175:2010 (following) Test duration: 240 h 168 h Rating 100°C (121°C): Test passed Diesel [CAS No. 68476-34-6]: Test passed IRM 901: Test passed IRM 902: Test passed Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DIN50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINEN60068-2-11:2000-02 Result: Test passed Test duration: 96 h Ambient conditions Ambient temperature (operation): -40°C ... 80°C Ambient temperature (assembly): + 15°C ... 35°C Recommended ambient temperature (storage/transport): 20°C ... 25°C Recommended humidity (storage/transport): 40 % ... 50 % Shelf life: 2years |
| Standards and regulations | Wipe resistance: DINEN61010-1 (VDE0411-1) |
| Mounting | Mounting type: adhesive |
| ECLASS | ECLASS-11.0: 27281102 ECLASS-12.0: 27281102 ECLASS-13.0: 27281102 |
| ETIM | ETIM 9.0: EC001530 |
