| Notes | General: Further information and detailed dimensions are available in the download area. |
| Product properties | Product type: Cover Type: Insertion plate Housing type: DIN rail housing Ventilation openings present: no Housing series: ME-MAX |
| Dimensions | Width: 41.8 mm Height: 73.6 mm Depth: 1 mm |
| Material specifications | Color: yellow (1018) Flammability rating according to UL 94: V0 CTI according to IEC 60112: 600 Surface characteristics: untreated Housing material: Polyamide |
| Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 55°C Ambient temperature (assembly): -5°C ... 100°C Relative humidity (storage/transport): 80 % |
| PCB data | Type of PCB mount: Latching |
| Mounting | Mounting type: Slot |
