Notes | General: Connectors may be operated only when there is no load/voltage. |
Product properties | Type: D7 Product type: Connector set Type of the screw connection: 1x M20 Series: HC-D Cable outlet: straight Insulation characteristics Degree of pollution: 3 |
Material specifications | Flammability rating according to UL 94: V0 Seal material: NBR Contact carrier material: PC Impact strength: IK06 Housing material: PA |
Cable/line | External cable diameter (): 4 mm ... 7 mm |
Mechanical properties | Mechanical data Type of the screw connection: 1x M20 |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 Impact strength: IK06 Ambient temperature (operation): -25°C ... 60°C |
Mounting | Mounting type: Latching with lower housing part |
ECLASS | ECLASS-11.0: 27440101 ECLASS-12.0: 27440113 ECLASS-13.0: 27440113 |
ETIM | ETIM 9.0: EC002636 |
UNSPSC | UNSPSC 21.0: 39121400 |
