HC-STA-RJ45GC-BWSC-PLRBK - Connector set
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Notes | General: Connectors may be operated only when there is no load/voltage. |
Product properties | Type: D7 RJ45 Product type: Connector set Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 Application: Data Protective cover: yes Series: HC-D Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
Electrical properties | Rated voltage (III/3): 50 V Rated surge voltage: 0.8 kV Rated current: 1 A Insulation resistance: 100 Mé Nominal voltage UN: 50 V Transmission characteristics (category): CAT6 |
Interfaces | Signal type/category: Ethernet CAT6 |
Material specifications | Material: PA Flammability rating according to UL 94: V0 Seal material: NBR Contact material: Copper alloy Contact surface material: Au Contact carrier material: PC Locking latch material: PA Impact strength: IK06 Housing material: PA |
Cable/line | Signal type/category: Ethernet CAT6 External cable diameter (): 4 mm ... 7 mm |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 Impact strength: IK06 Ambient temperature (operation): -40°C ... 70°C |
Mounting | Mounting type: Wall mounting |
ECLASS | ECLASS-11.0: 27440101 ECLASS-12.0: 27440113 ECLASS-13.0: 27440113 |
ETIM | ETIM 9.0: EC002636 |
UNSPSC | UNSPSC 21.0: 39121400 |
