1255580 PHOENIX CONTACT - Technology Bsa

EML-LPR-D (85,6X54)R YE - Label

Label, detectable, Roll, yellow, unlabeled, can be labeled with: THERMOMARKE.300 (D)/600 (D), THERMOMARK ROLL 2.0, THERMOMARK ROLL, THERMOMARK ROLL X1, THERMOMARK ROLLMASTER 300/600, THERMOMARK X1.2, mounting type: adhesive, lettering field size: 85.6x54mm, Number of individual labels: 600

Product Code: 1255580

Partner cod.: 1255580

PHOENIX CONTACT

Product properties	Product type: Device marking Marking Number of individual labels: 600 Number of individual labels per row: 1 Identification technology: Thermal transfer for rolls
Mounting	Mounting type: adhesive
Material specifications	RoHS compliant: yes Adhesive: Acrylic Color: yellow Material: Polyester Components: free from silicone and halogen
Environmental and real-life conditions	Test for substances that would hinder coating with paint or varnish Result: Test passed UV resistance Specification: ISO4892-2:2013-03 IEC 60068-2-2:2007-07 Result: Test passed Test duration: 96 h Duration: 96h Maximum temperature: 100°C Wipe resistance of inscriptions Specification: DINEN61010-1 (VDE0411-01):2020-03 DINEN62208 (VDE0660-511):2012-06 (in parts) Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DIN50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINEN60068-2-11:2000-02 Result: Test passed Ambient conditions Ambient temperature (operation): -40°C ... 100°C Recommended storage conditions: 23°C/50% relative humidity. Storage in a dry and dark place in the original packaging is recommended. Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % Shelf life: 6months
Dimensions	Width: 85.6 mm Length: 54 mm
Standards and regulations	Wipe resistance: DINEN61010-1 (VDE0411-1)
Notes	General: Due to the differing detection properties of metal detectors, the installer/end user must check suitability for the actual application For the THERMOMARK ROLL and THERMOMARK ROLL 2.0 roll printers, this material can only be processed with an external media hub. The rating plates, when used as intended, comply with the provisions of Regulation (EC) No. 1935/2004 of the European Parliament and of the Council of 27October2004 on materials and articles intended to come into contact with foodstuffs as well as the German Food and Feed Code. The rating plates EML-LPR-D (...x..)R xx can be safely used for the identification of food processing machines.
