Notes | General: Please note that an adapter listed under âAccessoriesâ is required to operate the device. Utilization restriction EMC note: EMC: class A product, see manufacturer's declaration in the download area |
Product properties | Product type: Monitor Computer data Processor: without Operating system: without operating system Cooling: passive RAM: without RAM Data storage system: without data storage Slots: without slots Extras: Shatter protection film Display Display type: 43.9 cm / 17.3"-TFT Screen resolution: 1920x1080Pixel(s)(Full HD) Touch technology: projective-capacitive (PCAP) Display lighting type: LED Brightness: 250cd/m² MTBF: 50000h Color spectrum: 16.2 million colors Reading angle left: 89° Reading angle right: 89° Reading angle top: 89° Reading angle bottom: 89° |
System properties | User software: without user software |
Electrical properties | Supply Supply voltage: 24 VDC Supply voltage range: 18 VDC ... 30 VDC |
Interfaces | Interfaces: 3x USB 2.0 1x USB server Optional interfaces: Without optional interface Monitor output: 1x DisplayPort 1x HDMI Network: Without network Bus system: without |
Dimensions | External dimensions Width / Height / Depth: 431 mm / 261 mm / 68 mm |
Material specifications | Material front plate: Glass (3 mm), hardened and non-reflective Housing material: Stainless steel, fully enclosed |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP69K Ambient temperature (operation): 0°C ... 50°C Permissible humidity (operation): 10 % ... 85 % (non-condensing) Permissible humidity (storage/transport): 10 % ... 85 % (non-condensing) Shock: DINEN60068-2-27 Vibration (operation): DINEN60068-2-6 |
Mounting | Mounting type: VESA holder (via adapter) Tube mounting (via adapter) Holder system: VESA MIS-D 100 C |
