Available
| Product properties | Product type: Data cable preassembled Sensor type: Sercos Number of positions: 4 No. of cable outlets: 1 Shielded: yes Coding: D Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Interfaces | Bus system: Sercos III Signal type/category: Sercos CAT5 (IEC 11801), 100 Mbps |
| Signaling | Status display: No Status display present: No |
| Electrical properties | Nominal voltage UN: 48 VÃAC 60 VÃDC Nominal current IN: 4 A Transmission medium: Copper Transmission characteristics (category): CAT5 (IEC 11801:2002) |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Material specifications | Flammability rating according to UL 94: V0 |
| Connector | Connection 1 Type: Plug straight M12 SPEEDCON / IP67 Number of positions: 4 Coding type: D Handle color: black Material: CuSn (Contact) Ni/Au (Contact surface) PA (Contact carriers) TPU, hardly inflammable, self-extinguishing (Grip) Zinc die-cast, nickel-plated (Screw connection) Insertion/withdrawal cycles: ââ°¥ 100 100 Contact resistance: ââ°¤ 5 mé Insulation resistance: ââ°¥ 100 Mé Tightening torque: 0.4 Nm Degree of protection: IP67 Ambient temperature (operation): -25°C ... 90°C Locking type: SPEEDCON Connection 2 Type: Plug straight M12 SPEEDCON / IP67 Number of positions: 4 Coding type: D Handle color: black Material: CuSn (Contact) Ni/Au (Contact surface) Zinc die-cast, nickel-plated (Screw connection) Zinc die-cast, nickel-plated (Screw connection) TPU, hardly inflammable, self-extinguishing (Grip) PA (Contact carriers) TPU, hardly inflammable, self-extinguishing (Grip) Insertion/withdrawal cycles: ââ°¥ 100 Insulation resistance: ââ°¥ 100 Mé Tightening torque: 0.4 Nm Ambient temperature (operation): -25°C ... 90°C Locking type: SPEEDCON |
| Cable/line | Cable length: 0.3 m Sercos IIIÃ[93K] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/4b34f8ad5d1bc342b90b879ccf8d3910/-S204x204-FJPG Cable weight: 68 kg/km UL AWM Style: 21694 (60ðC / 600ÃV) Number of positions: 4 Shielded: yes Cable type: Sercos IIIÃ[93K] Conductor structure: 1x4xAWG22/7, SF/TQ Signal runtime: 5.3 ns/m Conductor structure signal line: 7x 0.25 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² Wire diameter incl. insulation: approx. 1.55 mm External cable diameter: 6.5 mm ñ0.2Ãmm Outer sheath, material: PVC External sheath, color: signal red RAL 3020 Conductor material: Tin-plated Cu litz wires Material wire insulation: PE Single wire, color: white, yellow, blue, orange Thickness, outer sheath: approx. 0.9 mm Type of pair shielding: Aluminum-lined polyester foil Overall twist: Star quad Max. conductor resistance: ââ°¤ 120 é/km Insulation resistance: ââ°¥ 0.5 Gé*km Coupling resistance: ââ°¤ 20.00 mé/m (at 10 Hz) Wave impedance: 100 é ñ15Ãé (at 100 MHz) Nominal voltage, cable: 600 V Test voltage Core/Core: 2000 V (50ÃHz, 1Ãmin.) Test voltage Core/Shield: 2000 V (50ÃHz, 1Ãmin.) Minimum bending radius, fixed installation: 3 x D Minimum bending radius, flexible installation: 7 x D Flame resistance: according to ULÃ1685 (CSA FT 4) Resistance to oil: Resistant to oil to a limited extent Other resistance: UV resistant According to ULÃ1581, Section 1200 Ambient temperature (operation): -40°C ... 70°C (cable, fixed installation) -40°C ... 70°C (Cable, flexible installation) Ambient temperature (installation): -20°C ... 60°C |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65/IP67/IP69K Ambient temperature (operation): -25°C ... 70°C (cable, fixed installation) -25°C ... 70°C (Cable, flexible installation) |
| Standards and regulations | M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 |
