| Mounting | Assembly instructions: Sealed to IP66/IP67/IP68 thanks to the use of the A-SEW-25-P-W flat gasket (item 1411284) |
| Product properties | Product type: Full screw connection Application: Ex No. of conductors: 1 Manufacturer: CMP Manufacturer Designation: 25 A2F S. STEEL GLAND Manufacturer product number: 25A2F1RA4 Shielded: no Execution of the strain relief: B |
| Ex data | Cable types that can be used: for unarmored cables Suited for EX-applications: yes |
| Characteristics | Category of shock impact: 10 Design, Strain relief: B |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/6b1a375ce0bf72409b3655c4e60f5aa7/-S204x204-FJPG Length: 41 mm Length of the connecting thread: 15 mm Wrench size, union nut: 36 mm Wrench size, support: 36 mm Hexagon angular dimension: 39.6 mm Thread type connection side: M25 x 1.5 Thread pitch: 1.5 mm |
| Material specifications | Color: Steel / stainless steel Seal material Cable seal: EPDM Material for screw connection: Stainless steel 316L |
| Cable/line | External cable diameter (): 11.1 mm ... 20 mm |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP66 (using the corresponding A-SEW-...P-W flat gasket) IP67 (using the corresponding A-SEW-...P-W flat gasket) IP68 (using the corresponding A-SEW-...P-W flat gasket) Ambient temperature (operation): -60°C ... 130°C (static) |
| Approvals | ATEX: Sira 13ATEX1068X Sira 13ATEX4074X Ex II 2/3G, II 1D, Ex d IIC Gb, Ex e IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Ex IM2 Ex d I Mb, Ex e I Mb IECEx: IECEx SIR 13.0023X Ex d IIC Gb, Ex e IIC Gb, Ex nR IIC Gc, Ex ta IIIC Da, Ex d I Mb, Ex e I Mb |
| Standards and regulations | EN Ex Standards/specifications: EN60079-0, -1, -7, -15, -31 IEC Ex Standards/specifications: IEC 60079-0, -1, -7, -15, -31 Cable glands Standards/specifications: EN50262 Cable glandsâ Standards/specifications: BS6121: Part 1:1989 Cable glandsââ Standards/specifications: IEC 62444 |
| ECLASS | ECLASS-11.0: 27144432 ECLASS-12.0: 27140801 ECLASS-13.0: 27140801 |
| ETIM | ETIM 9.0: EC000441 |
| UNSPSC | UNSPSC 21.0: 39121300 |
