CUC-DSC-J1BAU-S/DSC28 - D-SUB crimp contact
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Product properties | Product type: Contacts Type: Individual female contact Contact material type: turned Series: HC-M-DSUB-C HC-M-08-GBIT HC-M-25 HC-M-EMV |
Electrical properties | Maximum load current: 5 A Rated surge voltage: 1.2 kV 1.2 kV (1 min.) Rated current: 5 A (at 20°C) |
Connection data | Maximum load current: 5 A |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/e1729e3b7365bb43b9e2ee3c511564f8/-S204x204-FJPG Width: 1.74 mm Height: 1.74 mm Length: 13.6 mm Mechanical characteristics Contact diameter: 1 mm |
Material specifications | Material: Metal Contact material: Copper alloy Contact surface material: 0.2 µm, gold over nickel |
Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠200 Insertion force per signal contact: ⤠3.40 N |
Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -55°C ... 130°C |
Standards and regulations | Standards/specifications: DIN41652 |
Mounting | Mounting type: Crimp connection Connection method: Crimp connection |
ECLASS | ECLASS-11.0: 27440204 ECLASS-12.0: 27440204 ECLASS-13.0: 27440204 |
ETIM | ETIM 9.0: EC000796 |
UNSPSC | UNSPSC 21.0: 39121500 |
