| Notes | General: This product corresponds to the PROFINET Cabling and Interconnection Technology Guideline for PROFINET regulations, version 2.00, order no: 2.252, Chapter 8.2 Connectors for Outside Environment (Balanced cabling) |
| Product properties | Product type: Data cable preassembled Sensor type: PROFINET Number of positions: 4 Application: Standard Shielded: yes Coding: D |
| Interfaces | Bus system: PROFINET Signal type/category: PROFINET CAT5 (IEC 11801), 100 Mbps |
| Signaling | Status display: No Status display present: No |
| Electrical properties | Nominal voltage UN: 48 VAC 60 VDC Nominal current IN: 1 A Transmission medium: Copper Transmission characteristics (category): CAT5 (IEC 11801:2002) |
| Connector | Connection 1 Type: Plug straight M12 SPEEDCON / IP67 Number of positions: 4 Coding type: D (Data) Handle color: black Material: CuSn (Contact) Ni/Au (Contact surface) PA (Contact carriers) TPU, hardly inflammable, self-extinguishing (Grip) Zinc die-cast, nickel-plated (Screw connection) Insertion/withdrawal cycles: ⥠100 100 Contact resistance: ⤠5 mé Insulation resistance: ⥠100 Mé Tightening torque: 0.4 Nm Degree of protection: IP67 Ambient temperature (operation): -25°C ... 90°C Locking type: SPEEDCON Connection 2 Type: Plug straight RJ45 / IP20 Number of positions: 4 (8) 4 Handle color: black Material: CuSn (Contact) Ni/Au (Contact surface) PA (Contact carriers) PA (Housing) Insertion/withdrawal cycles: ⥠750 Ambient temperature (operation): -25°C ... 80°C Degree of protection: IP20 |
| Cable/line | Cable length: 100 m PROFINET robot CAT5[93R] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/332e7b7c0f61684089bb5f28ed260786/-S204x204-FJPG Cable weight: 55 kg/km UL AWM Style: 20233 (80°C/300 V) Number of positions: 4 Shielded: yes Cable type: PROFINET robot CAT5[93R] Conductor structure: 1x4xAWG22/19, S/TQ Signal runtime: 4.8 ns/m Conductor structure signal line: 19x 0.15 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² Wire diameter incl. insulation: 1.5 mm External cable diameter: 6.5 mm ±0.2mm Outer sheath, material: PUR External sheath, color: green RAL 6018 Conductor material: Tin-plated Cu litz wires Material wire insulation: Foamed PE Single wire, color: white, yellow, blue, orange Thickness, outer sheath: approx. 1 mm Overall twist: Star quad Optical shield covering: 85 % Insulation resistance: ⥠500 Mé*km Loop resistance: ⤠120.00 é/km Wave impedance: 100 é ±5é (at 100 MHz) Nominal voltage, cable: 300 V Test voltage Core/Core: 2000 V (50Hz, 1min.) Test voltage Core/Shield: 2000 V (50Hz, 1min.) Minimum bending radius, fixed installation: 5 x D Torsion force: ± 180°/m Torsion cycles: 1000000 Shield attenuation: 2.9 dB (with 1 MHz) 5 dB (at 4 ÃHz) 8.1 dB (at 10 MHz) 10.4 dB (at 16 MHz) 11.9 dB (at 20ÃHz) 15.5 dB (at 31.25ÃHz) 26.5 dB (at 62.5ÃHz) 41 dB (at 100 MHz) Halogen-free: according to IEC 60754-1 Flame resistance: according to IEC 60332-1-2 Resistance to oil: in accordance with DINEN60811-2-1 Other resistance: UV resistant According to UL1581, Section 1200 Ambient temperature (operation): -40°C ... 80°C Ambient temperature (installation): -20°C ... 60°C |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67/IP20 Ambient temperature (operation): -25°C ... 90°C (M12 connector) -25°C ... 80°C (RJ45 connector) |
| Standards and regulations | M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 |
| ECLASS | ECLASS-11.0: 27060307 ECLASS-12.0: 27060307 ECLASS-13.0: 27060307 |
| ETIM | ETIM 8.0: EC001855 |
| UNSPSC | UNSPSC 21.0: 26121600 |
