| Product properties | Product type: Network distributor box Number of positions: 2 Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Electrical properties | Nominal voltage UN: ⤠32 VDC Nominal current IN: 4 A Transmission medium: Copper |
| Connection data | Connection technology Connection method: AS-i penetration technique |
| Interfaces | Bus system: AS-Interface |
| Signaling | Status display: No Status display present: No |
| Material specifications | Seal material: Neoprene FKM |
| Connector | Connection 1 Type: Load center AS-i Screw locking Number of positions: 2 Material: CuZn (Contact) Sn (Contact surface) PA (Contact carriers) PA (Housing) Locking type: Screw locking mechanism Connection 2 Type: Socket straight M12 Number of positions: 2 (5) 2 Material: Zinc die-cast, nickel-plated (Screw connection) Insertion/withdrawal cycles: ⥠100 Tightening torque: 0.4 Nm |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 Ambient temperature (operation): -25°C ... 70°C Ambient temperature (storage/transport): -25°C ... 70°C |
| Standards and regulations | Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 |
| Mounting | Connection method: AS-i penetration technique |
| ECLASS | ECLASS-11.0: 27440106 ECLASS-12.0: 27440106 ECLASS-13.0: 27440106 |
| ETIM | ETIM 9.0: EC002925 |
| UNSPSC | UNSPSC 21.0: 31251500 |
