| Product properties | Product type: Cable by the meter Number of positions: 18 Application: Distributor boxes LED: No |
| Electrical properties | Nominal voltage UN: 300 VAC 300 VDC |
| Cable/line | Cable length: 50 m PUR/PVC black[PUR] Number of positions: 18 Shielded: no Cable type: PUR/PVC black[PUR] Conductor structure signal line: 42x 0.10 mm AWG signal line: 22 Conductor cross section: 16x 0.34 mm² (Signal line) 2x 0.75 mm² (Power supply) External cable diameter: 10.1 mm ±0.2mm Outer sheath, material: PUR External sheath, color: deep black RAL 9005 Conductor material: Bare Cu litz wires Material wire insulation: PVC Single wire, color: brown, blue, white, green, yellow, gray, pink, red, black, violet, gray/pink, red/blue, white/green, brown/green, white/yellow, yellow/brown, white/gray, gray/brown Overall twist: Wires twisted in layers Nominal voltage, cable: 300 V (Signal line) 500 V (Power supply) Test voltage: 1200 V (Signal line) 2000 V (Power supply) Max. bending cycles: 1500000 Flame resistance: DINEN50265 Resistance to oil: according to VDE 0472 Part 803 Other resistance: Highly resistant to acids, alkaline solutions and solvents Special properties: Silicone-free Ambient temperature (operation): -40°C ... 90°C (cable, fixed installation) -5°C ... 80°C (Cable, flexible installation) |
| ECLASS | ECLASS-11.0: 27060106 ECLASS-12.0: 27060106 ECLASS-13.0: 27060106 |
| ETIM | ETIM 9.0: EC003250 |
| UNSPSC | UNSPSC 21.0: 26121600 |
