| Product properties | Product type: Cable by the meter Number of positions: 19 Application: Distributor boxes |
| Electrical properties | Nominal voltage UN: 300 VAC 300 VDC |
| Cable/line | Cable length: 200 m PUR/PVC black[PUR] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/d30eea0a677da64eabc3381e76b117f4/-S204x204-FJPG Cable weight: 183.7 kg/km UL AWM Style: 20549 (80°C/300 V) Number of positions: 19 Shielded: no Cable type: PUR/PVC black[PUR] Conductor structure signal line: 28x 0.15 mm AWG signal line: 20 Conductor cross section: 16x 0.5 mm² (Signal line) 3x 1 mm² (power line) Wire diameter incl. insulation: 1.5 mm ±0.1mm (Signal line) 2.1 mm ±0.1mm (power line) External cable diameter: 10.5 mm ±0.2mm Outer sheath, material: PUR External sheath, color: black RAL9005 Conductor material: Bare Cu litz wires Material wire insulation: PVC Single wire, color: brown, blue, green/yellow, white, green, yellow, gray, pink, red, black, violet, gray/pink, red/blue, white/green, brown/green, white/yellow, yellow/brown, white/gray, gray/brown Inner sheath thickness: ⥠0.15 mm Thickness, outer sheath: ⥠0.76 mm Overall twist: Wires twisted in layers Nominal voltage, cable: 300 V Test voltage: 2000 V Minimum bending radius, fixed installation: 7.5 x D Minimum bending radius, flexible installation: 10 x D Max. bending cycles: 1500000 Flame resistance: according to DINEN50265 Resistance to oil: according to VDE 0472 Part 803 Other resistance: Highly resistant to acids, alkaline solutions and solvents Special properties: Silicone-free Ambient temperature (operation): -40°C ... 90°C (cable, fixed installation) -5°C ... 80°C (Cable, flexible installation) |
| ECLASS | ECLASS-11.0: 27060106 ECLASS-12.0: 27060106 ECLASS-13.0: 27060106 |
| ETIM | ETIM 9.0: EC003250 |
| UNSPSC | UNSPSC 21.0: 26121600 |
