PTS 0,5/ 2-PH-5,75 BKRD KNX - PCB connector

PCB connector, nominal cross section: 0.5 mm², color: multicolored, nominal current: 6 A, rated voltage (III/2): 320 V, contact surface: Sn, contact connection type: Socket, number of rows: 1, number of positions: 2, product range: PTS 0,5/..-PH, pitch: 5.75 mm, connection method: Push-in spring connection, conductor/PCB connection direction: 0 °, locking clip: - without locking clip, plug-in system: COMBICON PST 1,0, locking: without, mounting: without, type of packaging: packed in cardboard

Product Code: 1574300

Partner cod.: 1574300

PHOENIX CONTACT

Product properties	Product type: PCB connector Product family: PTS 0,5/..-PH Product line: COMBICON Connectors XS Number of positions: 2 Pitch: 5.75 mm Number of rows: 1 Data management status Article revision: 00
Electrical properties	Nominal current I_N: 6 A Nominal voltage U_N: 320 V Contact resistance: 1.4 mÃ© Rated voltage (III/3): 250 V Rated surge voltage (III/3): 4 kV Rated voltage (III/2): 320 V Rated surge voltage (III/2): 4 kV Rated voltage (II/2): 400 V Rated surge voltage (II/2): 4 kV
Connection data	Interlock Locking type: without Mounting flange: without Conductor connection Connection method: Push-in spring connection Conductor/PCB connection direction: 0 ° Conductor cross section rigid: 0.34 mm² ... 0.75 mm² Cylindrical gauge a x b / diameter: - / 1.0 mm Stripping length: 5 mm
Material specifications	Material data - contact Note: WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 Contact material: Cu alloy Surface characteristics: tin-plated Metal surface terminal point (top layer): Tin (- 2 Ãµm Sn) Metal surface terminal point (middle layer): Nickel (- 0.76 Ãµm Ni) Metal surface contact area (top layer): Tin (- 2 Ãµm Sn) Metal surface contact area (middle layer): Nickel (- 0.76 Ãµm Ni) Material data - housing Color (Housing): multicolored () Insulating material: PA Insulating material group: I CTI according to IEC 60112: 600 Flammability rating according to UL 94: V0
Dimensions	Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/154300/full/b1500?format=jpg Pitch: 5.75 mm Width [w]: 12.45 mm Height [h]: 10 mm Length [l]: 10 mm
Mechanical tests	Conductor connection Specification: IEC 60999-1:1999-11 Result: Test passed Test for conductor damage and slackening Specification: IEC 60999-1:1999-11 Result: Test passed Repeated connection and disconnection Specification: IEC 60999-1:1999-11 Result: Test passed Pull-out test Specification: IEC 60999-1:1999-11 Conductor cross section/conductor type/tractive force setpoint/actual value: 0.34 mm² / solid / > 15 N 0.75 mm² / solid / > 30 N Resistance of inscriptions Specification: IEC 60068-2-70:1995-12 Result: Test passed Visual inspection Specification: IEC 60512-1-1:2002-02 Result: Test passed Dimension check Specification: IEC 60512-1-2:2002-02 Result: Test passed
Environmental and real-life conditions	Durability test Specification: IEC 60512-9-1:2010-03 Impulse withstand voltage at sea level: 4.8 kV Contact resistance R₁: 1.4 mÃ© Contact resistance R₂: 1.6 mÃ© Insertion/withdrawal cycles: 25 Insulation resistance, neighboring positions: > 5 MÃ© Climatic test Specification: ISO 22479:2019-05 Corrosive stress: 0.2 dm³SO₂on 300 dm³/40 °C/1 cycle Thermal stress: 100 °C/168 h Power-frequency withstand voltage: 2.21 kV Ambient conditions Ambient temperature (operation): -60 °C ... 100 °C (dependent on the derating curve) Ambient temperature (storage/transport): -40 °C ... 70 °C Relative humidity (storage/transport): 30 % ... 70 % Ambient temperature (assembly): -5 °C ... 100 °C
Electrical tests	Thermal test \| Test group C Specification: IEC 60512-5-1:2002-02 Tested number of positions: 2 Insulation resistance Specification: IEC 60512-3-1:2002-02 Insulation resistance, neighboring positions: > 5 MÃ© Air clearances and creepage distances \| Specification: IEC 60664-1:2020-05 Insulating material group: I Comparative tracking index (IEC 60112): CTI 600 Rated insulation voltage (III/3): 250 V Rated surge voltage (III/3): 4 kV minimum clearance value - non-homogenous field (III/3): 3 mm minimum creepage distance (III/3): 3.2 mm Rated insulation voltage (III/2): 320 V Rated surge voltage (III/2): 4 kV minimum clearance value - non-homogenous field (III/2): 3 mm minimum creepage distance (III/2): 3 mm Rated insulation voltage (II/2): 400 V Rated surge voltage (II/2): 4 kV minimum clearance value - non-homogenous field (II/2): 3 mm minimum creepage distance (II/2): 3 mm
Packaging specifications	Type of packaging: packed in cardboard
