RC-0000000M0FZ - Sleeve housing for coupler connector
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Product properties | Product type: Sleeve housings Connection profile: 12 Application: Signal Series: RC Shielded: yes Thread type: M23 |
Material specifications | Seal material: FPM or NBR or EPDM Housing material: Turned parts: copper zinc alloy (CuZn), die-cast parts: zinc (GD-Zn), plastic parts: SPS Metal Gasket and O-ring material: FPM |
Connector | Type: straight plastic-sheathed |
Cable/line | External cable diameter: 2 mm ... 10.5 mm |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 Ambient temperature (operation): -20°C ... 125°C Altitude: 2000 m |
Mounting | Connection method: Crimp connection |
ECLASS | ECLASS-11.0: 27440224 ECLASS-12.0: 27440224 ECLASS-13.0: 27440224 |
ETIM | ETIM 8.0: EC000437 |
UNSPSC | UNSPSC 21.0: 31261500 |
