Product properties | Product type: Circular connector (cable-side) |
Connector | Insulating body Coding: N Insertion/withdrawal cycles: 50 Connection method: Solder cup Contact switching type: Socket Application: Signal Number of positions: 6 Direction of rotation: Standard Connection profile: 6 Contact diameter Power contacts: 2 mm Litz wire cross-section Power contacts min.: 0.08 mm² Litz wire cross-section Power contacts max.: 2.5 mm² Rated current Power contacts: 20 A Rated voltage: 48 VAC 74 VDC Rated surge voltage: 1.5 kV Overvoltage category: III Degree of pollution: 3 |
ECLASS | ECLASS-11.0: 27371392 ECLASS-13.0: 27371392 ECLASS-12.0: 27371392 |
ETIM | ETIM 8.0: EC002498 |
UNSPSC | UNSPSC 21.0: 39121100 |
