PHOENIX CONTACT 1598010
PHOENIX CONTACTNot available

RC-12P2N12AD00 - Device connector front mounting

Device connector front mounting, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1240908
Product Code: 1598010
Partner cod.: 1598010
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Download
Tecnichal data
MountingMounting: 4x Ø 3.2
Connection method: Solder connection
Product propertiesProduct type: Circular connectors (device side)
Number of positions: 12
Connection profile: 12
Application: Signal
Series: RC
Shielded: yes
Coding: N
Thread type: M23
Material specificationsFlammability rating according to UL 94: V0
Seal material: FPM
Electrical propertiesContact
Contact diameter: 1 mm
Min. cross section: 0.08 mm²
Max. cross section: 1 mm²
Max. current: 8 A
Nominal voltage UN: 48 VAC 74 VDC
Overvoltage category: III
Degree of pollution: 3
Rated surge voltage: 1.5 kV
Connection dataConductor connection
Connection method: Solder connection
Contact connection type: Pin
Mechanical propertiesMechanical data
Insertion/withdrawal cycles: 50
ConnectorType: angled rotatable
Direction of rotation: Counter direction
Environmental and real-life conditionsAmbient conditions
Degree of protection: IP67
Ambient temperature (operation): -20°C ... 125°C
Altitude: 2000 m
Technical Specs
ECLASSECLASS-11.0: 27440109
ECLASS-12.0: 27440109
ECLASS-13.0: 27440109
ETIMETIM 8.0: EC003569
UNSPSCUNSPSC 21.0: 39121400
