| Notes | General: Order crimp contacts 8 x à 1 mm, 1 x à 2 mm separately |
| Mounting | Connection method: Crimp connection |
| Product properties | Product type: Circular connector (cable-side) Number of positions: 9 Connection profile: 8+1 Application: Signal Series: NC RC RM TU UC Coding: N |
| Connection data | Conductor connection Connection method: Crimp connection |
| Electrical properties | Contact Contact diameter: 2 mm Min. cross section: 1.5 mm² Max. cross section: 2.5 mm² Max. current: 20 A Nominal voltage UN: 48 VAC 74 VDC Overvoltage category: III Degree of pollution: 3 Rated surge voltage: 1.5 kV Contactâ Contact diameter: 1 mm Min. cross section: 0.14 mm² Max. cross section: 0.56 mm² Max. current: 8 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: 50 |
| Connector | Direction of rotation: Standard |
| ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
| ETIM | ETIM 8.0: EC002635 |
| UNSPSC | UNSPSC 21.0: 39121400 |
