PHOENIX CONTACT 1611578

Not available

RC-1RP1NT242TJ - Device connector, rear mounting

M23, Device connector, rear mounting, series: RC, straight, shielded: yes, Screw locking mechanism, contact connection type: Pin, Radial O-ring, 4x M2.5, Panel thickness min.: 2.7 mm, Panel thickness max.: 3.5 mm, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1242595

Product Code: 1611578

Partner cod.: 1611578

PHOENIX CONTACT

Tecnichal data

Technical Specs

Download

Tecnichal data

Product properties	Product type: Circular connectors (device side)
Connector	Insulating body Contact switching type: Pin Application: Signal Housing Housing material: Metal Type of locking: Screw locking mechanism Pg screw connection: none Degree of protection (plugged in): IP67 Thread type: M23

Technical Specs

ECLASS	ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116
ETIM	ETIM 8.0: EC002635
UNSPSC	UNSPSC 21.0: 39121400

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Manufacturer_declaration_05486.pdf

Manufacturer_declaration_11101.pdf
