RC-12S1N8A80ZS - Cable connector
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Mounting | Connection method: Crimp connection |
Product properties | Product type: Circular connector (cable-side) Number of positions: 12 Connection profile: 17 Application: Signal Series: RC Shielded: yes Coding: N Thread type: M23 |
Material specifications | Seal material: NBR Housing material: Metal |
Connection data | Conductor connection Connection method: Crimp connection |
Electrical properties | Contact Contact diameter: 1 mm Max. current: 8 A Nominal voltage UN: 48 VAC 74 VDC Overvoltage category: III Degree of pollution: 3 Rated surge voltage: 1.5 kV |
Mechanical properties | Mechanical data Insertion/withdrawal cycles: 100 |
Connector | Type: straight Direction of rotation: Standard |
Cable/line | External cable diameter: 3 mm ... 10.5 mm |
Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 IP65 Altitude: 2000 m |
ECLASS | ECLASS-11.0: 27440102 ECLASS-12.0: 27440116 ECLASS-13.0: 27440116 |
ETIM | ETIM 8.0: EC002635 |
UNSPSC | UNSPSC 21.0: 39121400 |
