PHOENIX CONTACT 1621432
PHOENIX CONTACTNot available

CA-12P2N8A2S00 - Device connector front mounting

M23, Device connector front mounting, series: CA, straight, shielded: yes, for standard and SPEEDCON interlock, No. of pos.: 12, Direction of rotation: Counter direction, contact connection type: Pin, Crimp connection, Flat gasket, 4x Ø 3.2, flange dimensions: 25 mm x 25 mm, coding: N
Product Code: 1621432
Partner cod.: 1621432
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Download
Tecnichal data
Product propertiesProduct type: Circular connectors (device side)
ConnectorInsulating body
Note: Order information: Order crimp contacts Ø 1 mm separately
Coding: N
Insulation body material: PA 6.6
Connection method: Crimp connection
Contact switching type: Pin
Application: Signal
Number of positions: 12
Direction of rotation: Counter direction
Connection profile: 12
Contact diameter Power contacts: 1 mm
Rated current Power contacts: 8 A
Rated voltage: 48 VAC
74 VDC
Rated surge voltage: 1.5 kV
Overvoltage category: III
Degree of pollution: 3
Housing
Housing material: GD-Zn
Flange dimensions: 25mm x 25mm
Type of locking: for standard and SPEEDCON interlock
Pg screw connection: none
Degree of protection (plugged in): IP67
Thread type: M23
Technical Specs
ECLASSECLASS-11.0: 27440312
ECLASS-12.0: 27440312
ECLASS-13.0: 27440312
ETIMETIM 8.0: EC002641
UNSPSCUNSPSC 21.0: 39121100
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Assembly_instructions_00030.pdf

Manufacturer_declaration_05486.pdf
