PHOENIX CONTACT 1622578

Not available

CA-Z0132 - Unshielded cable clamp type cage

Unshielded cable clamp type cage, shielded: no, cable diameter range: 3 mm ... 14.5 mm, series: CA

Product Code: 1622578

Partner cod.: 1622578

PHOENIX CONTACT

Tecnichal data

Technical Specs

Download

Tecnichal data

Product properties	Product type: Mounting material Type of the screw connection: universal without shield Series: CA Shielded: no
Cable/line	External cable diameter: 3 mm ... 14.5 mm
Mechanical properties	Mechanical data Type of the screw connection: universal without shield

Technical Specs

ECLASS	ECLASS-11.0: 27440290 ECLASS-12.0: 27440290 ECLASS-13.0: 27440290
ETIM	ETIM 9.0: EC002943
UNSPSC	UNSPSC 21.0: 39121100

Download

PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Manufacturer_declaration_05486.pdf

Other products

Description other products

PHOENIX CONTACT 1621434

CA-12S2N8A80DN - Cable connector
Cod. Articolo: 1621434

M23, Cable connector, series: CA, straight, shielded: yes, Screw locking mechanism, No. of pos.: 12, Direction of rotation: Counter direction, contact connection type: Socket, Crimp connection, cable diameter range: 3 mm ... 14.5 mm, coding: N, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1244398

PHOENIX CONTACT 1606058

UC-0000000R3DU - Sleeve housing for cable connector
Cod. Articolo: 1606058

Sleeve housing for cable connector, straight, Screw locking mechanism, M23, shielded: yes, cable diameter range: 10 mm ... 14 mm

PHOENIX CONTACT 1623256

HC-26S1N8A80DU - Cable connector
Cod. Articolo: 1623256

Cable connector, straight, Screw locking mechanism, M27, number of positions: 26, contact connection type: Socket, shielded: yes, degree of protection: IP67, when plugged in, cable diameter range: 2 mm ... 14.5 mm, number of positions: 26, connection method: Crimp connection, series: HC, Alternative product in accordance with RoHS II without Exemption6c (Pb<0.1%) item no.: 1244829
