HC-B 24-A-UT-PER-M - Terminal adapter

HEAVYCON terminal adapter male insert, B24 series, 24-pos., left protective conductor connection for the right side of the control cabinet, screw connection.

Product Code: 1648108

Partner cod.: 1648108

PHOENIX CONTACT

Notes	General: For HEAVYCON-ADVANCE mounting flange and HEAVYCON panel mounting base of B24 type Connectors may be operated only when there is no load/voltage.
Product properties	Type: B24 for the right side of the control cabinet Product type: Terminal adapter Number of positions: 24 Connection profile: 24+PE Contact numbering: 1 - 24 Series: HC-B Screwdriver blade: 0.5 x 3.5 mm Insulation characteristics Overvoltage category: III Degree of pollution: 3
Electrical properties	Rated voltage (III/3): 500 V Rated surge voltage: 6 kV Rated current: 16 A SCCR: 5 kA (UL 2237)
Connection data	Connection technology Connection technology: Screw connection Connection in acc. with standard: IEC / EN Conductor connection Conductor cross section: 0.5 mm² ... 2.5 mm² Connection cross section AWG: 20 ... 14 Tightening torque: 0.5 Nm ... 0.8 Nm Stripping length of the individual wire: 12 mm
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/5112626cc421484ab12ced29854ed17b/-S204x204-FJPG Width: 34 mm Height: 71.6 mm Length: 111 mm Drill hole distance, horizontal: 104 mm Drill hole distance, vertical: 27 mm
Material specifications	Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Ag Contact carrier material: PA Standards/regulations: PA: Fire protection in rail vehicles - requirement sets R22, R23, and R24 acc. to DINÃENÃ45545-2 (Risk level HL1 - HL3)
Cable/line	Stripping length of the individual wire: 12 mm
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 500
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -40°C ... 125°C
Standards and regulations	Constructional and testing regulations: DINÃENÃ61984 DINÃENÃ60664 IEC 60352 Tests: DINÃENÃ61984 DINÃENÃ60664 IEC 60352 Testing Standards/regulations: PA: Fire protection in rail vehicles - requirement sets R22, R23, and R24 acc. to DINÃENÃ45545-2 (Risk level HL1 - HL3)
Mounting	Assembly instructions: To ensure correct use, installation in housing with IP54 protection or better is required Connectors may only be actuated when there is no load/voltage.
