VS-BU-KX-75-RG179/187 - D-SUB coaxial contact
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Product properties | Product type: Solder contact Type: Individual female contact Contact material type: turned Series: HC-M-04-KOAX |
Electrical properties | Rated voltage (III/3): 250 V Rated current: 2 A Insulation resistance: 10 Té Wave impedance: 75 é |
Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/4562c6d29f76834ab4aca339b5cf64bc/-S204x204-FJPG Length: 23 mm Mechanical characteristics Contact diameter: 4.8 mm |
Material specifications | Contact material: Copper alloy Contact surface material: Hard gold-plated over nickel |
Cable/line | External cable diameter (): 3.2 mm Wave impedance: 75 é |
Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠500 Insertion force per signal contact: ⤠7.00 N Extraction force per signal contact: ⤠7 N |
Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -55°C ... 135°C |
Mounting | Connection method: Solder cup |
ECLASS | ECLASS-11.0: 27440204 ECLASS-12.0: 27440204 ECLASS-13.0: 27440204 |
ETIM | ETIM 9.0: EC000796 |
UNSPSC | UNSPSC 21.0: 39121500 |
