| Notes | General: Further information and detailed dimensions are available in the download area. |
| Product properties | Product type: Cover Housing type: DIN rail housing Housing series: ME-MAX Product family: ME MAX 45.. Type: Insertion plate Ventilation openings present: no |
| Dimensions | Width: 41.8 mm Height: 73.6 mm Depth: 1 mm |
| Material specifications | Color (Insertion plate): red (RAL 3001) Flammability rating according to UL 94: V0 CTI according to IEC 60112: 600 Housing material: Polyamide Surface characteristics: untreated |
| Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40 °C ... 105 °C (depending on power dissipation) Ambient temperature (storage/transport): -40 °C ... 55 °C Ambient temperature (assembly): -5 °C ... 100 °C Relative humidity (storage/transport): 80 % |
| PCB data | Type of PCB mount: Latching |
| Mounting | Mounting type: Slot |
