FK-MPT 0,5/ 8-ST-3,5 NZ88975H5 - PCB connector

PCB connector, nominal cross section: 0.5 mm², color: green, nominal current: 4 A, rated voltage (III/2): 250 V, contact surface: Tin, contact connection type: Socket, number of potentials: 8, number of rows: 1, number of positions: 8, number of connections: 16, product range: FK-MPT 0,5/..-ST, pitch: 3.5 mm, connection method: Push-in spring connection, conductor/PCB connection direction: 0°, pin layout: Linear pinning, plug-in system: COMBICON PST 1,0, locking: without, mounting: without, type of packaging: packed in cardboard

Product Code: 1712445

Partner cod.: 1712445

PHOENIX CONTACT

Product properties	Product line: COMBICON Connectors XS Product type: PCB connector Product family: FK-MPT 0,5/..-ST Number of positions: 8 Pitch: 3.5 mm Number of connections: 16 Number of rows: 1 Mounting flange: without Number of potentials: 8 Pin layout: Linear pinning
Electrical properties	Nominal current I_N: 4 A Nominal voltage U_N: 250 V Degree of pollution: 3 Rated voltage (III/3): 160 V Rated surge voltage (III/3): 2.5 kV Rated voltage (III/2): 250 V Rated surge voltage (III/2): 2.5 kV Rated voltage (II/2): 250 V Rated surge voltage (II/2): 2.5 kV
Connection data	Interlock Locking type: without Mounting flange: without Conductor connection Connection method: Push-in spring connection Conductor/PCB connection direction: 0° Conductor cross section rigid: 0.12 mm² ... 0.5 mm² Conductor cross section AWG: 26 ... 20 Stripping length: 6.5 mm
Material specifications	Material data - contact Note: WEEE/RoHS-compliant, free of whiskers according to IEC 60068-2-82/JEDEC JESD 201 Contact material: Cu alloy Surface characteristics: hot-dip tin-plated Metal surface terminal point (top layer): Tin (5 - 7 Ãµm Sn) Metal surface terminal point (middle layer): Nickel (2 - 3 Ãµm Ni) Metal surface contact area (top layer): Tin (5 - 7 Ãµm Sn) Metal surface contact area (middle layer): Nickel (2 - 3 Ãµm Ni) Material data - housing Color (Housing): green (6021) Insulating material: PBT Insulating material group: IIIa CTI according to IEC 60112: 225 Flammability rating according to UL 94: V0 Material data Ã¢Ã¢¬Ã¢ actuating element Color (Actuating element): orange (2003)
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/e1234e2392bde14688da8fe58a63c0c9/-S204x204-FJPG Pitch: 3.5 mm Width [w]: 28.5 mm Height [h]: 8.5 mm Length [l]: 9.5 mm
Mounting	Pin layout: Linear pinning Connection method: Push-in spring connection
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -40°C ... 100°C (dependent on the derating curve) Ambient temperature (storage/transport): -40°C ... 70°C Relative humidity (storage/transport): 30 % ... 70 % Ambient temperature (assembly): -5°C ... 100°C
Electrical tests	Air clearances and creepage distances \| Specification: IEC 60664-1:2007-04 Insulating material group: IIIa Comparative tracking index (IEC 60112): CTI 225 Rated insulation voltage (III/3): 160 V Rated surge voltage (III/3): 2.5 kV minimum clearance value - non-homogenous field (III/3): 1.5 mm minimum creepage distance (III/3): 2.5 mm Rated insulation voltage (III/2): 250 V Rated surge voltage (III/2): 2.5 kV minimum clearance value - non-homogenous field (III/2): 1.5 mm minimum creepage distance (III/2): 2.5 mm Rated insulation voltage (II/2): 250 V Rated surge voltage (II/2): 2.5 kV minimum clearance value - non-homogenous field (II/2): 1.5 mm minimum creepage distance (II/2): 2.5 mm
Packaging specifications	Type of packaging: packed in cardboard
