HC-D 4-2ST - Shield connection clamp
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
![](https://www.technologybsa.com/wp-content/uploads/2023/08/copia.png)
Notes | General: for HC-D40, HC-D64 contact carriers |
Product properties | Product type: Shield connection Contact material type: turned |
Electrical properties | Rated voltage (III/3): 60 V |
Connection data | Connection technology Connection method: Crimp connection |
Dimensions | Mechanical characteristics Contact diameter: 1.6 mm |
Material specifications | Contact material: Copper alloy Contact surface material: hard-silver plated |
Cable/line | External cable diameter (): 6 mm ... 9 mm |
Mechanical properties | Mechanical data Insertion/withdrawal cycles: ⥠500 |
Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 60°C |
Mounting | Connection method: Crimp connection |
ECLASS | ECLASS-11.0: 27440192 ECLASS-12.0: 27440192 ECLASS-13.0: 27440192 |
ETIM | ETIM 9.0: EC002943 |
UNSPSC | UNSPSC 21.0: 39121400 |
