2200118 PHOENIX CONTACT - Technology Bsa

HBUS 53,6-16P-1S PMC2 BK - DIN rail bus connectors

DIN rail connector, color: black, nominal current: 3 A (Total current of 25A max.), rated voltage (III/2): 30 V, number of positions: 16, pitch: 2.54 mm, mounting: DIN rail mounting, locking: without

Product Code: 2200118

Partner cod.: 2200118

PHOENIX CONTACT

Product properties	Product type: DIN rail connector Product family: HBUS16 Number of positions: 16 Pitch: 2.54 mm
Electrical properties	Nominal current I_N: 3 A (Total current of 25A max.) Degree of pollution: 3 Contact resistance: 23.9 mÃ© Rated voltage (III/3): 30 V Rated surge voltage (III/3): 0.8 kV Rated voltage (III/2): 30 V Rated surge voltage (III/2): 0.8 kV Rated voltage (II/2): 100 V Rated surge voltage (II/2): 0.8 kV
Dimensions	Pitch: 2.54 mm Width [w]: 53.6 mm Height [h]: 13.6 mm Length [l]: 37.1 mm
Material specifications	Material data - contact Contact material: Cu alloy Surface characteristics: Completely gold-plated Material data - housing Color (Housing): black (9005) Insulating material: PA Insulating material group: I CTI according to IEC 60112: 600 Flammability rating according to UL 94: V0
Connector	Connection 1 Insulating material: PA CTI according to IEC 60112: 600
Electrical tests	Air clearances and creepage distances \| Specification: IEC 60664-1:2007-04 Insulating material group: I Rated insulation voltage (III/3): 30 V Rated surge voltage (III/3): 0.8 kV minimum clearance value - non-homogenous field (III/3): 0.8 mm minimum creepage distance (III/3): 1.3 mm Rated insulation voltage (III/2): 30 V Rated surge voltage (III/2): 0.8 kV minimum clearance value - non-homogenous field (III/2): 0.2 mm minimum creepage distance (III/2): 0.53 mm Rated insulation voltage (II/2): 100 V Rated surge voltage (II/2): 0.8 kV minimum clearance value - non-homogenous field (II/2): 0.2 mm minimum creepage distance (II/2): 0.71 mm
Mechanical tests	Visual inspection Specification: IEC 60512-1-1:2002-02 Result: Test passed Dimension check Specification: IEC 60512-1-2:2002-02 Result: Test passed
Environmental and real-life conditions	Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 150 - 10 Hz Sweep speed: 1octave/min 20m/s² Amplitude: 0.15mm (10Hz...58.1Hz) Test duration per axis: 2.5 h Durability test Specification: IEC 60512-9-1:2010-03 Impulse withstand voltage at sea level: 0.91 kV Contact resistance R₁: 23.9 mÃ© Contact resistance R₂: 24 mÃ© Insertion/withdrawal cycles: 25 Climatic test Specification: DIN50018:2013-05 Corrosive stress: 0.2 dm³SO₂on 300 dm³/40°C/1 cycle Thermal stress: 100°C/168h Power-frequency withstand voltage: 0.55 kV Glow-wire test Specification: IEC 60695-2-10:2013-04 Temperature: 850°C Time of exposure: 30 s Shocks Specification: IEC 60068-2-27:2008-02 Pulse shape: Semi-sinusoidal Acceleration: 150m/s² Shock duration: 11ms Test directions: X-, Y- and Z-axis (pos. and neg.) Ambient conditions Ambient temperature (operation): -40°C ... 105°C (dependent on the derating curve) Ambient temperature (storage/transport): -40°C ... 55°C Relative humidity (storage/transport): 80 % Ambient temperature (assembly): -5°C ... 100°C
Mounting	Mounting type: DIN rail mounting
Packaging specifications	Outer packaging type: Carton
