PHOENIX CONTACT 2200157
PHOENIX CONTACTNot available

UM-PRO 108 FOOT BK - Foot element

Press-drawn section housings, DIN rail mounting, Base element for the DIN rail, for mounting below UM-PRO PROFILE (width: 108mm), color: black (9005), Foot element
Product Code: 2200157
Partner cod.: 2200157
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Download
Tecnichal data
NotesGeneral: Refer to the data sheet for the range in the download area.
Product propertiesProduct type: Base latches
Product family: UM-PRO
Type: Base element for the DIN rail, for mounting below UM-PRO PROFILE (width: 108Âmm)
Housing type: Press-drawn section housings
Housing series: UM-PRO
Material specificationsColor: black (9005)
Flammability rating according to UL 94: V0
Surface characteristics: untreated
Housing material: Polyamide
Environmental and real-life conditionsThermal stability / ball thrust test
Specification: IEC 60695-10-2:2014-02
Temperature: 125°C
Test duration: 1 h
Force: 20 N
Mechanical strength / tumbling barrel
Specification: IEC 60068-2-31:2008-05
Height of fall: 50Âcm
Frequency: 50
Ambient conditions
Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation)
Ambient temperature (storage/transport): -40°C ... 55°C
Ambient temperature (assembly): -5°C ... 100°C
Relative humidity (storage/transport): 80 %
MountingMounting type: DIN rail mounting
Packaging specificationsType of packaging: packed in cardboard
Outer packaging type: Carton
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Data_sheet_03040.pdf

Material_description_00001.pdf

Technical_drawing_35602.pdf
