PHOENIX CONTACT 2200161
PHOENIX CONTACTNot available

UM-PRO PE CONTACT L1 - Functional ground contact

PE contact for UM-PRO panel mounting base for connecting the PCB to the DIN rail at level 1
Product Code: 2200161
Partner cod.: 2200161
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Description
Download
Tecnichal data
NotesGeneral: Refer to the data sheet for the range in the download area.
Product propertiesProduct type: Ground contact
Product family: UM-PRO
Type: top PCB level
Housing type: Press-drawn section housings
Housing series: UM-PRO
DimensionsWidth: 6 mm
Height: 20.8 mm
Depth: 34.3 mm
PCB design
PCB thickness: 1.4 mm ... 1.8 mm
Material specificationsColor: silver
Housing material: Steel
Environmental and real-life conditionsAmbient conditions
Ambient temperature (operation): -40°C ... 105°C
Ambient temperature (assembly): -5°C ... 100°C
PCB dataThickness of the PCB: 1.4 mm ... 1.8 mm
MountingMounting type: Screw mounting
Tightening torque / speed: Mounting the PCB: 0.5 Nm-0.6 Nm / 500 rpm-1000 rpm
Packaging specificationsOuter packaging type: Resealable bag
Technical Specs
ECLASSECLASS-11.0: 27182701
ECLASS-13.0: 27190605
ETIMETIM 9.0: EC002779
UNSPSCUNSPSC 21.0: 31261500
Description
PE contact for UM-PRO panel mounting base for connecting the PCB to the DIN rail at level 1
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Data_sheet_03040.pdf

Material_description_00001.pdf

Technical_drawing_35606.pdf
