| Product properties | Type: Pin strip Product type: Pin strip Product family: PSTD 0,65X0,65/..-V Number of positions: 18 Pitch: 2.54 mm Number of connections: 18 Number of rows: 2 Number of potentials: 18 Pin layout: Linear pinning |
| Electrical properties | Degree of pollution: 3 Contact resistance: 35.7 mé |
| Mounting | Mounting type: THR soldering Pin layout: Linear pinning |
| Material specifications | Material data - housing Color (Housing): black (9005) Insulating material: PA Flammability rating according to UL 94: V0 |
| Dimensions | Pitch: 2.54 mm Width [w]: 22.86 mm Height [h]: 37.8 mm Length [l]: 5 mm Pin dimensions: 0.635 x 0.635 mm |
| Mechanical tests | Visual inspection Specification: IEC 60512-1-1:2002-02 Result: Test passed Dimension check Specification: IEC 60512-1-2:2002-02 Result: Test passed |
| Environmental and real-life conditions | Vibration test Specification: IEC 60068-2-6:2007-12 Frequency: 10 - 150 - 10 Hz Sweep speed: 1octave/min 20m/s² Amplitude: 0.15mm (10Hz...58.1Hz) Test duration per axis: 2.5 h Durability test Specification: IEC 60512-9-1:2010-03 Impulse withstand voltage at sea level: 1.75 kV Contact resistance R1: 35.7 mé Contact resistance R2: 35.7 mé Insertion/withdrawal cycles: 25 Climatic test Specification: DIN50018:2013-05 Corrosive stress: 0.2 dm3 SO2 on 300 dm3/40°C/1 cycle Thermal stress: 100°C/168h Power-frequency withstand voltage: 0.84 kV Shocks Specification: IEC 60068-2-27:2008-02 Pulse shape: Semi-sinusoidal Acceleration: 150m/s² Shock duration: 11ms Test directions: X-, Y- and Z-axis (pos. and neg.) |
| ECLASS | ECLASS-11.0: 27460201 ECLASS-12.0: 27460201 ECLASS-13.0: 27460201 |
| ETIM | ETIM 9.0: EC002637 |
| UNSPSC | UNSPSC 21.0: 39121400 |
