PHOENIX CONTACT 2203224
PHOENIX CONTACTNot available

ME-IO 18,8 F-LR 7035 VPE200 - Filler plug

DIN rail housing, Filler plug, for closing the Lock and Release area, width: 11.7 mm, height: 16.1 mm, depth: 10.6 mm, color: light grey (7035)
Product Code: 2203224
Partner cod.: 2203224
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Technical Specs
Description
Download
Tecnichal data
Product propertiesProduct type: Filler plug
Type: Filler plug
Housing type: DIN rail housing
Ventilation openings present: no
Housing series: ME-IO
DimensionsWidth: 11.7 mm
Height: 16.1 mm
Depth: 10.6 mm
Material specificationsColor: light grey (7035)
Flammability rating according to UL 94: V0
Surface characteristics: untreated
Housing material: Polyamide
Environmental and real-life conditionsAmbient conditions
Max. IP code to attain: IP20
Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation)
Ambient temperature (storage/transport): -40°C ... 55°C
Ambient temperature (assembly): -5°C ... 100°C
Relative humidity (storage/transport): 80 %
MountingMounting type: Latching
Mounting position: Vertical (horizontal DIN rail)
Technical Specs
ECLASSECLASS-11.0: 27182702
ECLASS-13.0: 27190605
ETIMETIM 8.0: EC001031
UNSPSCUNSPSC 21.0: 31261500
Description
DIN rail housing, Filler plugs, for closing the Lock and Release area, width: 11.7 mm, height: 16.1 mm, depth: 10.6 mm, color: light gray (7035)
