PHOENIX CONTACT 2695853
PHOENIX CONTACTNot available

UM 72-SEFE/L KMGY - Lateral element

Press-drawn section housings, DIN rail mounting, Lateral element (left), color: light grey (7035), with snap-on foot, width: 5 mm, height: 89.6 mm, depth: 37.6 mm
Product Code: 2695853
Partner cod.: 2695853
PHOENIX CONTACT


Diminuisci la quantità
Aumenta la quantità
Tecnichal data
Download
Tecnichal data
Product propertiesProduct type: Panel mounting base side part
Product family: UM72
Type: Lateral element (left)
Housing type: Press-drawn section housings
Ventilation openings present: no
Housing series: UM
DimensionsWidth: 5 mm
Height: 89.6 mm
Depth: 37.6 mm
Material specificationsColor: light grey (7035)
Flammability rating according to UL 94: V0
Surface characteristics: untreated
Housing material: Polyamide
Environmental and real-life conditionsAmbient conditions
Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation)
Ambient temperature (storage/transport): -40°C ... 55°C
Ambient temperature (assembly): -5°C ... 100°C
Relative humidity (storage/transport): 80 %
MountingMounting type: DIN rail mounting
Download
PER SCARICARE I DOCUMENTI E' NECESSARIO EFFETTUARE L'ACCESSO AL SITO

Material_description_00001.pdf

Technical_drawing_37539.pdf

Technical_drawing_37540.pdf
