2700786 PHOENIX CONTACT - Technology Bsa

Dimensions	Width: 289 mm Height: 127 mm Depth: 122 mm
Notes	Utilization restriction EMC note: EMC: class A product, see manufacturer's declaration in the download area
Material specifications	Material base plate: Die-cast aluminum, corrosion-resistant Housing surface material: Stainless steel, smooth, corrosion-resistant
Mounting	Mounting type: DIN rail mounting
Interfaces	Ethernet Connection method: RJ45 Note on the connection method: Auto negotiation and autocrossing Transmission speed: 10/100 Mbps Transmission physics: Copper Transmission length: 100 m (per segment) Signal LEDs: Supply voltage, data transmission, error, link, activity No. of channels: 4 (RJ45 ports) EthernetÃ¢Ã¢¬Ã¢¹ Connection method: via interface module Note on the connection method: Max. 4 interface modules (without extension) Transmission speed: 10/100 Mbps (full duplex) Transmission physics: multi-mode fiberglass Single-mode fiberglass POF-SCRJ GI-HCS fibers Copper PoE Signal LEDs: Data receive, link status No. of channels: 2 (Per interface module) Ethernet (combo) Connection method: SFP/RJ45 Transmission speed: 1000 Mbps (full duplex) Transmission physics: FO Copper Transmission length: up to 80 km (Depending on the fiber/SFP module used) Wavelength: 850Ãnm / 1310Ãnm / 1550Ãnm No. of channels: 4 (SFP ports or RJ45 ports) Ethernet (combo)Ã¢Ã¢¬Ã¢¹ Connection method: SFP/RJ45 Note on the connection method: Either SFP port or RJ45 port active Transmission speed: 10/100/1000 Mbps (SFP module:Ã1000ÃMbps) Transmission physics: Copper or SFP module Transmission length: up to 80 km (Depending on the fiber/SFP module used) Wavelength: 850Ãnm / 1310Ãnm / 1550Ãnm Signal LEDs: Data receive, link status No. of channels: 4 (Combo ports) Serial (RS-232) Connection method: RS-232-C, 6-pos. MINI-DIN socket (PS/2)
Product properties	Type: Stand-Alone Product type: Switch Product family: Managed Switch GHS Insulation characteristics Protection class: III (IEC 61140, ENÃ61140, VDEÃ0140-1) Switch functions Diagnostic functions: RMON History N:1-Portmirroring LLDP (Link Layer Discovery Protocol) SNMP-Traps Basic functions: Store-and-forward switch complies with IEEE 802.3, 8 priority classes according to IEEE 802.1p, smart mode, port mirroring, multicast filtering, IGMP snooping, VLANs, Media Redundancy Protocol (MRP according to IEC 62439), Rapid Spanning Tree (RSTP), Fast Ring Detection (FRD), Large Tree Support, IEEE 802.1X security, port security, SNMPv3, HTTPS, PROFINET device, GMRP, GVRP, SNTP, 2 digital inputs Signal contact control voltage: 24 V (typical) Signal contact control current: 190 mA (maximum) PROFINET conformance class: Conformance-Class B PROFINET device function: PROFINET device PROFIenergy Fast Startup PROFINET specification: Version 1.1 Filter functions: Quality of Service (8 priority classes) Port-Priorisierung VLAN (up to 223 VLANs) Management: Web-based management (HTTP) SNMPv1/v2/v3 Redundancy: MRP (Media Redundancy Protocol) RSTP (Rapid Spanning Tree Protocol) FRD (Fast Ring Detection) Large Tree Support STP (Spanning Tree Protocol) MSTP (Multiple Spanning Tree Protocol) Status and diagnostic indicators: LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link and switchable Activity/Speed/Duplex), DI1, DI2 (Digital Input), UI (supply voltage for ext. sensor), and large operator display (display of IP address and other parameters) Supported browsers: Internet Explorer 5.5 or higher Additional functions: DHCP Option 82 (Relay Agent) Link aggregation (up to 8 trunks) BootP DHCP-Client MAC-based Port-Security Jumbo frames Security functions Basic functions: Store-and-forward switch complies with IEEE 802.3, 8 priority classes according to IEEE 802.1p, smart mode, port mirroring, multicast filtering, IGMP snooping, VLANs, Media Redundancy Protocol (MRP according to IEC 62439), Rapid Spanning Tree (RSTP), Fast Ring Detection (FRD), Large Tree Support, IEEE 802.1X security, port security, SNMPv3, HTTPS, PROFINET device, GMRP, GVRP, SNTP, 2 digital inputs
Electrical properties	Power consumption: typ. 19 W (without plugged-in interface modules) Local diagnostics: US1/2 Supply voltage US1, US2 Green LED FAIL Div. LED red LINK Link status Green LED MODE Data transmission speed Green LED MODE Data transmission speed Green/orange LED Maximum power dissipation for nominal condition: 19.2 W Transmission medium: Copper FO Supply Supply voltage (DC): 24 VÃDC (redundant) Supply voltage range: 18.5 VÃDC ... 30.2 VÃDC Power supply connection: Via COMBICON, max. conductor cross section 2.5 mm² Residual ripple: 3.6 V_PP (within the permitted voltage range) Max. current consumption: 2.7 A Typical current consumption: 800 mA (up to 2.5 A, depends on the configuration) Function Signal contact control voltage: 24 V (typical) Signal contact control current: 190 mA (maximum)
Connection data	Connection method: Screw connection Conductor cross section, rigid: 0.2 mm² ... 2.5 mm² Conductor cross section, flexible: 0.2 mm² ... 2.5 mm² Conductor cross section AWG: 24 ... 12 Stripping length: 7 mm
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 55°C (non-condensing) Ambient temperature (storage/transport): -20°C ... 70°C Permissible humidity (operation): 10 % ... 95 % (non-condensing) Permissible humidity (storage/transport): 10 % ... 95 % (non-condensing) Vibration (operation): in acc. with IEC 60068-2-6: 5g, 150 Hz Air pressure (operation): 80 kPa ... 108 kPa (2000Ãm above mean sea level) Air pressure (storage/transport): 66 kPa ... 108 kPa (3500Ãm above sea level)
Standards and regulations	Free from substances that could impair the application of coating: In acc. with VW specification
EMC data	Conformance with EMC directives: IEC 61000-4-2 (ESD) Criterion B, Class 3 IEC 61000-4-3 (immunity to radiated interference) Criterion A, 10ÃV/m IEC 61000-4-4 (burst) Criterion A, 1 kV IEC 61000-4-5 (surge) Criterion B IEC 61000-4-6 (immunity to conducted interference) Criterion A, 10 Vrms EN 55022 (emitted interference) ClassÃA Noise immunity: EN 61000-6-2:2005 Electromagnetic compatibility: Conformance with EMC Directive 2014/30/EU Noise emission: EN 61000-6-3/-4
System properties	Functionality Basic functions: Store-and-forward switch complies with IEEE 802.3, 8 priority classes according to IEEE 802.1p, smart mode, port mirroring, multicast filtering, IGMP snooping, VLANs, Media Redundancy Protocol (MRP according to IEC 62439), Rapid Spanning Tree (RSTP), Fast Ring Detection (FRD), Large Tree Support, IEEE 802.1X security, port security, SNMPv3, HTTPS, PROFINET device, GMRP, GVRP, SNTP, 2 digital inputs System requirements Supported browsers: Internet Explorer 5.5 or higher
Signaling	Status display: LEDs: US1, US2 (power supply), Fail (alarm contact), 2 LEDs per Ethernet port (Link and switchable Activity/Speed/Duplex), DI1, DI2 (Digital Input), UI (supply voltage for ext. sensor), and large operator display (display of IP address and other parameters)
