| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/418b78014174d342b4d3452c35b898da/-S204x204-FJPG Width: 45 mm Height: 130 mm Depth: 119 mm |
| Notes | General: Support by phone or on-site (fee is charged) |
| Material specifications | Housing material: Polycarbonate fiber reinforced |
| Mounting | Mounting type: DIN rail mounting |
| Interfaces | Ethernet (RJ45) Number of interfaces: 8 Connection method: RJ45 Note on the connection method: Auto negotiation and autocrossing Transmission speed: 10/100 Mbps Transmission physics: Copper Transmission length: 100 m (per segment) Signal LEDs: Data receive, link status No. of channels: 8 (RJ45 ports) |
| Product properties | Type: Book type Product type: Switch Product family: Managed Switch 2000 MTTF: 507.8 Years (SNÃ29500 standard, temperatureÃ25°C, operating cycleÃ21%) 246.55 Years (SNÃ29500 standard, temperatureÃ40°C, operating cycleÃ34.25%) 56.66 Years (SNÃ29500 standard, temperatureÃ55°C, operating cycleÃ100%) Signal delay: ââ°¥ 6.5 õs (Store and Forward mode, 10/100 Mbps, depending on the frame size) Insulation characteristics Protection class: III (VDEÃ0106) Degree of pollution: 2 Switch functions Diagnostic functions: RMON History LLDP (Link Layer Discovery Protocol) SNMP-Traps N:1-Portmirroring ACD (Address Conflict Detection) SysLog CRC-Surveillance Basic functions: Store-and-forward switch, complies with IEEEÃ802.3 PROFINET conformance class: Conformance-Class A Filter functions: Quality of Service (8 priority classes) Class of Service DiffServ/DSCP Port-Priorisierung VLAN (up to 8 VLANs) IGMP Snooping/Querier (v1/v2) Auto-Query-Port Extended Multicast Filtering IP parameterization: DHCP-Client DHCP server (port based) BootP MAC address table: 8k Management: Web-based management (HTTP/HTTPS) Role-based user management (LDAP) SNMPv1/v2/v3 Command Line Interface (Telnet, SSH) Redundancy: MRP (Media Redundancy Protocol) RSTP (Rapid Spanning Tree Protocol) Status and diagnostic indicators: LEDs: US (power supply), 2 LEDs per Ethernet port (Link/Activity and Speed) Additional functions: Transmission of MMSÃandÃGOOSE (IEC 61850-8-1) Transmission of Modbus/TCP Time synchronization: SNTP (Simple Network Time Protocol) Security functions Basic functions: Store-and-forward switch, complies with IEEEÃ802.3 |
| Electrical properties | Local diagnostics: US Supply voltage Green LED LNK/ACT Link status Green LED SPD Data transmission speed Green LED Maximum power dissipation for nominal condition: 4.86 W (At US = 18 V DC and 60°C ambient temperature) Test voltage: 500 VÃDC Test section: for one minute 500 VÃDC Transmission medium: Copper Supply Supply voltage (DC): 24 VÃDC (single) Supply voltage range: 18 VÃDC ... 32 VÃDC Power supply connection: via COMBICON, max. conductor cross section 1.5 mm² Residual ripple: 3.6 VPP (within the permitted voltage range) Max. current consumption: 0.35 A (At US = 18 V DC and 60°C ambient temperature) Typical current consumption: 180 mA (at US = 24ÃVÃDC and 25ðC ambient temperature) Current consumption: 180 mA |
| Connection data | Connection method: Push-in spring connection Note on the connection method: Use only copper connecting cables providing the permitted temperature range (-40ðC ... 75ðC). Conductor cross section, rigid: 0.25 mm² ... 1.5 mm² Conductor cross section, flexible: 0.25 mm² ... 1.5 mm² Conductor cross section AWG: 24 ... 16 Stripping length: 9 mm |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): 0°C ... 60°C Ambient temperature (storage/transport): -40°C ... 85°C Permissible humidity (operation): 10 % ... 95 % (non-condensing) Permissible humidity (storage/transport): 10 % ... 95 % (non-condensing) Shock (operation): 30g (ENÃ60068-2-27) Vibration (operation): 2g, according to IEC 60068-2-6 Air pressure (operation): 86 kPa ... 108 kPa (1500Ãm above sea level) Air pressure (storage/transport): 86 kPa ... 108 kPa (1500Ãm above sea level) |
| Standards and regulations | Free from substances that could impair the application of coating: Yes |
| Approvals | UL, USA/Canada Identification: cULus Note: ULÃ61010-1, Ed.Ã3 / ULÃ61010-2-201, Ed.Ã1, CSA C22.2 NO.61010-2-201:14. Ed.Ã1 / CSA C22.2 NO.61010-1-12. Ed.Ã3 |
| EMC data | Conformance with EMC directives: EN 61000-6-2 EN 61000-4-2 (ESD) Criterion B EN 61000-6-2 EN 61000-4-3 (electromagnetic fields) Criterion A EN 61000-6-2 EN 61000-4-4 (EFT burst) Criterion A EN 61000-6-2 EN 61000-4-5 (surge) Criterion B EN 61000-6-2 EN 61000-4-6 (line noise immunity) Criterion A EN 61000-6-2 EN 61000-6-4 (interference) ClassÃA EN 61000-6-2 EN 61000-6-4 (conducted interference) ClassÃA Noise immunity: EN 61000-6-2 Electromagnetic compatibility: Conformance with EMC Directive 2014/30/EU Noise emission: EN 61000-6-4 |
| System properties | Functionality Basic functions: Store-and-forward switch, complies with IEEEÃ802.3 |
| Signaling | Status display: LEDs: US (power supply), 2 LEDs per Ethernet port (Link/Activity and Speed) |
