Not available
| Notes | General: Refer to the data sheet for the range in the download area. |
| Product properties | Product type: Mounting material Housing type: DIN rail housing Ventilation openings present: no Housing series: ME |
| Dimensions | Width: 30.5 mm Height: 88 mm Depth: 22.8 mm |
| Material specifications | Color: blue grey (7031) Flammability rating according to UL 94: V0 Surface characteristics: untreated Housing material: Polyamide |
| Environmental and real-life conditions | Ambient conditions Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 55°C Ambient temperature (assembly): -5°C ... 100°C Relative humidity (storage/transport): 80 % |
